User’s Guide
LNI-2 DC
Better Power
Super Low Noise DC Power Filter & Stabilizer
Galvanic Isolation between Input and Output
Integrated HF / RF Filter
Universal 9 – 18 Volt DC Input
12 Volt 2 A 24 Watts DC Output
Ultra Low Noise µFilter
Sensor Technology
Overload and Overheating Protection
Short Circuit Proof
GND Connection Option
Compact & Portable
2
User’s Guide LNI-2 DC © RME
Heat Notice
Surface may become hot during operation – ensure sufficient ventilation.
Avoid direct sun light and do not place it near other sources of heat, like radi-
ators or stoves. Leave some space between this device and others for venti-
lation.
Unauthorized servicing/repair voids warranty. Only use accessories
specified by the manufacturer.
Read the manual completely. It includes all information necessary
to use and operate this device.
Important Notes ......................................................... 2
General
1 Introduction ............................................................... 4
2 Package Contents ..................................................... 4
3 Proper Use ................................................................. 4
4 Brief Description and Characteristics ..................... 4
5 Connectors – LED ..................................................... 5
5.1 Connector Pinouts ................................................... 5
6 Installation and First Time Operation ...................... 6
7 Using the ground Terminal ...................................... 6
8 Hotline – Troubleshooting ........................................ 6
Technical Reference
9 Technical Specifications
9.1 DC Input ................................................................. 8
9.2 DC Output µFilter ................................................... 8
9.3 General................................................................... 8
10 Technical Background
10.1 Differences Linear and Switched Power Supply .... 9
10.2 Galvanic Isolation ................................................. 10
10.3 Leakage Current .................................................. 10
10.4 µFilter ................................................................... 11
10.5 Influence of load on DC output voltage ................ 11
10.6 Measurements ..................................................... 12
11 Block Diagram LNI-2 DC ......................................... 13
Miscellaneous
12 Accessories ............................................................. 16
13 Warranty ................................................................... 16
14 Appendix .................................................................. 16
15 Declaration of Conformity ...................................... 17
