Page 1/2
Container: Models 2981GN, 2982BR, 2983BG, 2984BR
Lid and Hardware Kit: Models 2987BL, 2988BL, 2989BL
Public Square
ยฎ
Recycling Containers
Select your preferred set of labels from the two sets
supplied (
H or I
). Carefully remove the center
strip of backing material from a label. Grasp label
as shown and line up with top edge of A Container
so that ends of label overhang container sides
equally. Press down at center of label, peel the
backing off one side of the label, and smooth out
toward one end, pushing out any air bubbles for a
smooth ๏ฌ nish. Repeat for the other end; then apply
the rest of the labels from this set to each remaining
side in the same manner.
1
๏€ ๎˜€
Black Lid w/2โ€ wide slot 1 F72613A3
Screw 2 Z10310A3
Wire Hold-Down Ring 1 F52920A3
Plastic Clip 2 Z10425A5
Leveling Glide 4 Z30227A3
Label Set, 4 โ€œPaperโ€ 1 Z40736A6
Label Set, 4 โ€œNewspaperโ€ 1 Z40879A3
๎˜€
๎˜€
๎˜€
๎˜€
๎˜€
๎˜€
๎˜€
LETTER
CODE
DESCRIPTION
QTY.
PART NO.
LID AND HARDWARE KITS
B
C
D
E
F
H
Black Lid w/4โ€ round hole 1 F72615A1
Screw 2 Z10310A3
Wire Hold-Down Ring 1 F52920A3
Plastic Clip 2 Z10425A5
Leveling Glide 4 Z30227A3
Label Set, 4 โ€œCansโ€ 1 Z40735A7
Label Set, 4 โ€œGlassโ€ 1 Z40734A8
๎˜€
๎˜€
๎˜€
๎˜€
๎˜€
๎˜€
๎˜€
LETTER
CODE
DESCRIPTION
QTY.
PART NO.
B
C
D
E
F
H
1002981 26โ€ Base only, Green
1002982 32โ€ Base only, Brown
1002983 38โ€ Base only, Burgundy
1002984 44โ€ Base only, Brown
DESCRIPTION
CONTAINER (one only)*
Letter
Code
๎˜€
A
Plastic Tray 1 Z50719A6
๎˜€
G
Black Lid w/8โ€ square opening 1 F72614A2
Screw 2 Z10310A3
Wire Hold-Down Ring 1 F52920A3
Plastic Clip 2 Z10425A5
Leveling Glide 4 Z30227A3
Label Set, 4 โ€œWasteโ€ 1 Z40733A9
Label Set, 4 โ€œPlasticโ€ 1 Z40880A0
๎˜€
๎˜€
๎˜€
๎˜€
๎˜€
๎˜€
๎˜€
LETTER
CODE
DESCRIPTION
QTY.
PART NO.
B
C
D
E
F
H
* Each of the above Containers includes
the following parts packed inside:
MODEL 2987BL
MODEL 2988BLMODEL 2989BL
Des. Pat. No. D332,681
๎˜€๏€
2
๎˜€
Model
Number
Thread four F Leveling Glides into the holes in
the bottom of A Container. Turn the container
upright and adjust glides until the container sits
level without rocking.
๎˜€
๎˜€
Safco Products Company, New Hope, MN 55428
100298737: 1 of 2; Rev A; Rev Date 04-AUG-2016
Line up set of holes in hinged
๏ฌ‚ ange of B Lid with outer set of
holes in inside rim of A Container.
Fasten with two C Screws.
3
๎˜€
Insert G Plastic Tray into bottom
of container to catch occasional
drips or leaks.
5
Open lid, lift wire hold-down ring. Insert bag into
opening and fold top edge of bag over three sides of
container (not wire/clip side)
6
Pull two back corners of bag under corners of wire
hold-down ring until bag is next to the plastic clips.
7
Slip two E Plastic Clips over
the wire on welded side of D
Wire Hold-Down Ring. Align
clips with inner holes on inside
rim ๏ฌ‚ ange, and press points of
clips ๏ฌ rmly into the holes.
4
TO INSERT PLASTIC BAGS:
Lower wire hold-down ring into place, tuck all bag
๏ฌ‚ aps neatly into inside of container (over the wire),
and close the lid.
8
๎˜€
๎˜€
๎˜€
For questions or concerns, please call
Safco Consumer Hot Line 1-800-664-0042
available Monday-Friday 7:30 AM to 5:00 PM
(Central Time)
(English-speaking operators)
๎˜€
๎˜€
Safco Products Company, New Hope, MN 55428
100298737: 2 of 2; Rev A; Rev Date 04-AUG-2016
