Scott Genius 950 Manual
Read below 📖 the manual in Italian for Scott Genius 950 (20 pages) in the Bicycle category. This guide has been helpful for 26 people and has been rated 4.5 stars on average by 2 users
Page 1/20
W W W . S C O T T - S P O R T S . C O M
WWW.SCOTT-SPORTS.COM
SCOTT Sports SA
Route du Crochet 17, CH–1762 Givisiez
Phone: +41 26 460 16 16 | Fax: +41 26 460 16 00
Email: scottsupport@scott-sports.com
All rights reserved © 2017 SCOTT Sports SA
Distribution:
SSG (Europe) Distribution Center SA, P.E.D. Zone C1, Rue du Kiell 60, 6790 Aubange, Belgium
v7.0/03072017
USER MANUAL
SCOTT GENIUS
WWW.SCOTT-SPORTS.COM
ENGLISHENGLISH
Genius Concept . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 04
Geometry/Technical Data Genius 27.5" & 29" . . . . . . . . . . . . . . . . . 05
TWINLOC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 06
B S Up of Shock & Fasic et- orks. . . . . . . . . . . . . . . . . . . . . . . . . . .07
SAG . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 08
R Shock S Upebound et- . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 09
R Rear Deplaceable ropout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
P Mivot aintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Wheels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
C Rable outing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
BB Standards/FD Mounting Details . . . . . . . . . . . . . . . . . . . . . . . . 17
Adjustment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Guarantee on SCOTT Bikes. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
•
CONTENTS
The SCOTT Genius should be adjusted exactly to the individual
rider to achieve maximum saftey and fun while riding.
SCOTT recommends that all adjustments be carried out by
your local authorized SCOTT dealer. Some basic maintenance
can be done if strictly following the manuals supplied with
this bike.
Please contact your authorized SCOTT dealer for advice in order
to avoid any harm and assist you with any questions or technical
problems.
03 |
BIKE USER MANUAL | GENIUSGENIUS | BIKE USER MANUAL
| 02
S / 900 S / 700 M / 900 M / 700 L / 900 L / 700 XL / 900 XL / 700
LOW BB Setting HIGH BB Setting LOW BB Setting HIGH BB Setting LOW BB Setting HIGH BB Setting LOW BB Setting HIGH BB Setting
A HEAD TUBE ANGLE 65.0 ° 65.6 ° 65.0 ° 65.6 ° 65.0 ° 65.6 ° 65.0 ° 65.6 °
B HEAD TUBE LENGTH 95.0 mm 3.7 in 95.0 mm 3.7 in 95.0 mm 3.7 in 95.0 mm 3.7 in 4.3 in 4.3 in 4.9 in 4.9 in110.0 mm 110.0 mm 125.0 mm 125.0 mm
C
TOP TUBE
HORIZONTAL
569.7 mm 22.4 in 568.2 mm 22.4 in 602.8 mm 23.7 in 601.2 mm 23.7 in 631.8 mm633.4 mm 24.9 in 24.9 in 670.1 mm 26.4 in 668.4 mm 26.3 in
D STANDOVER HEIGHT
E BB OFFSET -1.1 in-27.4 mm -20.0 mm -20.0 mm -20.0 mm -20.0 mm-0.8 in -1.1 in-27.5 mm -0.8 in -1.1 in-27.6 mm -0.8 in -1.1 in-27.8 mm -0.8 in
F BB HEIGHT 346.1 mm 13.6 in 13.4 in 346.0 mm 13.6 in340.0 mm 340.0 mm 340.0 mm 340.0 mm13.4 in 345.9 mm 13.6 in 13.4 in 345.7 mm 13.6 in 13.4 in
G WHEEL BASE 1,165.9 mm 45.9 in 1,164.6 mm 45.9 in 1,198.9 mm 1,197.6 mm 1,232.1 mm47.2 in 47.1 in 48.5 in 48.5 in1,230.8 mm 1,271.3 mm 50.1 in 50.0 in1,270.0 mm
H
BB CENTER TO
TOPTUBE CENTER
I
BB CENTER TO TOP OF
SEATTUBE
410.0 mm 410.0 mm 440.0 mm 440.0 mm 480.0 mm 480.0 mm 520.0 mm 520.0 mm16.1 in 16.1 in 17.3 in 17.3 in 18.9 in 18.9 in 20.5 in 20.5 in
J SEAT ANGLE 74.7 ° 75.3 ° 75.3 ° 75.3 ° 75.3 °74.7 ° 74.8 ° 74.8 °
K CHAINSTAY 438.0 mm 436.0 mm 438.0 mm 436.0 mm 438.0 mm 436.0 mm 438.0 mm 436.0 mm17.2 in 17.2 in 17.2 in 17.2 in 17.2 in 17.2 in 17.2 in 17.2 in
L REACH 405.9 mm 16.0 in 16.2 in 439.1 mm412.0 mm 17.3 in 445.0 mm 17.5 in 466.1 mm 18.4 in 18.6 in 499.2 mm 19.7 in 505.0 mm 19.9 in472.0 mm
M STACK 599.7 mm 23.6 in 595.5 mm 23.4 in 599.9 mm 23.6 in 595.5 mm 23.4 in 613.7 mm 609.2 mm 622.8 mm24.2 in 24.0 in 24.7 in627.5 mm 24.5 in
N STEM LENGTH 40.0 mm 1.6 in 1.6 in 2.0 in 2.0 in 2.0 in 2.0 in 2.0 in 2.0 in40.0 mm 50.0 mm 50.0 mm 50.0 mm 50.0 mm 50.0 mm 50.0 mm
0 TRAIL 117.7 mm 4.6 in 4.2 in 4.6 in 4.2 in 4.6 in 4.2 in107.3 mm 117.6 mm 107.3 mm 117.5 mm 107.3 mm 117.4 mm 4.6 in 4.2 in107.3 mm
ENGLI SHENGLISH
•
GENIUS CONCEPT
The Genius has been a longstanding staple in our range of Mountain Bikes for many years
now. Having always been the result of a focus on innovation, technology and design, the
Genius has evolved over the years in order to be able to tame anything that comes its way.
With the latest iteration of our all mountain trail bike, one concept formed the backbone of
the development process. What comes down, must go up. This has always been the premise
of the Genius, it truly is the perfect MTB for every trail it encounters.
Steep rooty climbs? No problem.
Fast, flowy single track? Yes please.
2000m long descents in the alps? Music to our ears.
With the Genius, no matter the trail, no matter the conditions, no matter the rider, it is always
the right tool for the job.
•
GEOMETRY/TECHNICAL DATA GENIUS 27.5" & 29"
Seatpost diameter 31.6mm
Seatube clamp 34.9mm
Headset Semi integrated cups 56mm
bottom/44mm top
BB housing PF92
Front derailleur Shimano high direct side swing (N/A on
HMX frames) additional parts needed
Chainring size 36T max
Shock Dimensions 185x55mm
Shock mount size 30x8mm
Max tire width 27.5 plus /2.8 tire (71mm)
29 / 2.6 tire (66mm)
Please note:
Tire sizes often vary from brand to brand.
Ensure the tire clearance is adequate
when replacing your tires!
05 |
BI KE U SER MA NUAL | GENIUSGENIUS | BIKE USER MANUAL
| 04
