Digital TV outdoor antenna
User´s manual
SDA 512
EN
Copyright ©, Fast ČR, a.s. Revision 11/2020
2
IMPORTANT SAFETY INSTRUCTIONS
THE LIGHTNING FLASH WITH ARROWHEAD SYMBOL WITHIN AN EQUILATERAL TRIANGLE IS INTENDED TO ALERT
THE USER TO THE PRESENCE OF UNINSULATED “DANGEROUS VOLTAGE“ WITHIN THE UNIT´S CABINET THAT MAY
BE OF SUFFICIENT MAGNITUDE TO CONSTITUTE A RISK OF ELECTRIC SHOCK TO PERSONS.
THE EXCLAMATION POINT WITHIN AN EQUILATERAL TRIANGLE IS INTENDED TO ALERT THE USER TO THE PRE-
SENCE OF IMPORTANT OPERATING AND MAINTENANCE (SER
VICING) INSTRUCTIONS IN THE MANUAL ACCOM-
PANYING THE UNIT.
THE APPARATUS SHALL NOT BE EXPOSED TO DRIPPING OR SPLASHING AND THAT NO OBJECTS FILLED WITH LI-
QUIDS, SUCH AS VASES, SHALL BE PLACED THE APPARATUS.
THE APLIANCE COUPLER IS USED AS THE DIS
CONNECT DEVICE, THE DISCONNECT DEVICE SHALL REMAIN READILY
OPERABLE.
ALWAYS REMEMBER TO REMOVE THE PLUG FROM THE MAINS SOCKET BEFORE DISCONNECTING THE POWER
LEAD FROM THE BACK OF THE UNIT.
DO NOT PLAC
E NAKED FLAME SOURCES, SUCH AS CANDLES, ON THE TOP.
WARNING:
TO PREVENT FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THE UNIT TO RAIN OR MOISTURE. NEVER ATTEMPT TO OPEN
THE CABINET. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
This symbol indicates that this product incorporates double insulation between hazardous mains voltage and user
accessible parts. When servicing use only identical replacement parts.
Suitable for outdoor use. Super quality reception for
digital terrestrial signals (DVB-T)
and radio programs (DAB radio pro-
grams) as well as FM radio signals.
Built in low noise and high gain circuit.
Gain control
Dual output
Easy to install and operate
Input voltage (AC110 – 120V or AC220 – 240V)
Working voltage (DC 5.0V / 0.55A / 2.75W)
Integrated 5G (LTE) Filter
Reception frequency: VHF: 47 – 230MHz, UHF: 470 - 694 MHz
Gain: VHF: 12 dB / UHF: 12 dB
Note:
Do not use while thunderstorm and turn o the power.
If you do not use the device or you are not using it for a long time, turn o the device and unplug from power outlet.
If reception is not su cient enough using this device, relocate the antenna to suitable place.
1.Mounting bracket installation
Attach mounting bracket to the antenna
(see Fig. 1) using the two screws and tigh-
ten  rmly.
Fig. 1
EN
Digital TV outdoor antenna
SDA 512
Copyright ©, Fast ČR, a.s. Revision 11/2020
3
2. Antenna installation
Loose the wing nuts, put the mast between mounting bracket, then tighten the wing nuts. Fig. 2
3. F–Connector installation
(1) Thread the coaxial cable through waterproof cap
(2) Snip o
10mm from the cover of coaxial cable
(3) Fold back the braid and snip o
8mm foaming core of coaxial cable.
(4) Thread the coaxial cable through F-type male plug.
(5) Now
nish installation
4. Connect the F-type male plug to F-type female plug of antenna and then cover waterproof cap.
Fig. 3 Fig. 4
EN
Digital TV outdoor antenna
SDA 512
Copyright ©, Fast ČR, a.s. Revision 11/2020
Connect the signal cable from the antenna to the
signal input jack of the power supply, connect the
power supply output jack to the digital receiver,
plug the power adaptor with the power supply and
connect to power socket, and
nally join the TV and
the digital receiver.
Connect the signal cable from the
antenna to the signal input jack of
the power supply, connect the power
supply output jack to the TV, plug the
power adaptor with the power supply
and connect to power socket.
Connect the signal cable from the
antenna to the signal input jack of
the power supply, connect the power
supply output jack to the TV, plug the
power adaptor with the power supply
and connect to power socket.
Connection and Usage
Product Specifications
| Brand: | Sencor |
| Category: | TV antenna |
| Model: | SDA 512 |
