Quick-Start Guide

To view manuals, FAQs, videos, drivers, downloads, technical drawings, and more, visit www.startech.com/support.

Manual Revision: April 5, 2022 1:28 PM

Product Diagram

(Side A)

USB-C 10Gbps Triple and Dual Monitor Docking Station - HDMI/DP/USB-C - 60W PD - Chromebook Certied

4 5

Component Function

1 Power LED

• Solid Green LED indicates the Dock is powered ON in 4-Lane

Mode (USB ports operate at USB 2.0 480 Mbps speed)

• Solid Orange LED indicates the Dock is powered ON in 2-Lane

Mode

• Hold Power Button for 4 seconds to switch between modes

2 Power Button

• Hold Power Button for 1 second to power the Dock ON and O

Screw-Locking

USB-C Host Port

• Connect to a USB-C Port on a Host Computer

• USB 3.2 Gen 2 (10 Gbps)

• Power Delivery 3.0 Specication

4 3.5mm Audio Port

• Connect an Audio Device

• 4 Position Audio Jack for Headset use

USB-A Data/Charge

Port

• Connect and/or charge a USB-A Peripheral

• USB 3.2 Gen 2 (10 Gbps) *USB 2.0 (480 Mbps) in 4-Lane Mode

• Supports BC 1.2 5 V/1.5 A (7.5 W) charging

• Requires Host Connection for Charging

USB-C Data/Charge

Port

• Connect and/or charge a USB-C Peripheral

• USB 3.2 Gen 2 (10 Gbps) *USB 2.0 (480 Mbps) in 4-Lane Mode

• Supports 5 V/1.5 A (7.5 W) charging

• Requires Host Connection for Charging

7 2x USB-A Data Ports

• Connect USB-A Peripherals

• USB 2.0 (480Mbps)

• Supports up to 5 V/0.5 A (2.5 W) charging

8 2x USB-A Data Ports

• Connect USB-A Peripherals

• USB 3.2 Gen 2 (10 Gbps) *USB 2.0 (480 Mbps) in 4-Lane Mode

• Supports up to 5 V/0.9 A (4.5 W) charging

Gigabit Ethernet

Port

• Connect the Docking Station to a Network Device, using a

Network Cable

• 10/100/1000 Mbps

USB-C Data/

Charge/DP Alt

Mode Video Port

(Video Output 1)

• Connect and/or charge a USB-C peripheral

• Connect a USB-C Display directly, or for any other Display, a

USB-C Video Adapter is required

• USB 3.2 Gen 2 (10Gbps) *USB 2.0 (480 Mbps) in 4-Lane Mode

• Supports 5 V/1.5 A (7.5 W) charging

• Display output via DisplayPort 1.4 DP Alt Mode

DisplayPort Video

Port

(Video Output 1)

• Connect a DisplayPort Display as Video Output #1

• DisplayPort 1.4

• Up to 4K (4096x2160) 60Hz

• Via DisplayPort 1.4 DP Alt Mode

HDMI Video Port

(Video Output 2)

• Connect an HDMI Display as Video Output #2

• HDMI 2.0b HDR10

• Up to 4K (4096x2160) 60Hz

• Via DisplayPort 1.4 DP Alt Mode

DisplayPort Video

Port

(Video Output 2)

• Connect a DisplayPort Display as Video Output #2

• DisplayPort 1.4

• Up to 4K (4096x2160) 60Hz

• Via DisplayPort 1.4 DP Alt Mode

HDMI Video Port

(Video Output 3)

• Connect an HDMI Display as Video Output #3

• HDMI 2.0b HDR10

• Up to 4K (4096x2160) 60Hz

• Via DisplayPort 1.4 DP Alt Mode

15 DC 20V Port

• Connect the Dock to a Power Source, using the Universal

Power Adapter

12 13 14 15

(Side B)

Product ID

DK31C3MNCR / DK31C3MNCRUE

Use of Trademarks, Registered Trademarks, and other Protected Names and Symbols

This manual may make reference to trademarks, registered trademarks, and other protected names and/or symbols of third-

party companies not related in any way to StarTech.com. Where they occur these references are for illustrative purposes only

and do not represent an endorsement of a product or service by StarTech.com, or an endorsement of the product(s) to which

this manual applies by the third-party company in question. StarTech.com hereby acknowledges that all trademarks, registered

trademarks, service marks, and other protected names and/or symbols contained in this manual and related documents are the

property of their respective holders.

Warranty Information

This product is backed by a 3-year warranty.

For further information on product warranty terms and conditions, please refer to www.startech.com/warranty.

Limitation of Liability

In no event shall the liability of StarTech.com Ltd. and StarTech.com USA LLP (or their ocers, directors, employees or agents)

for any damages (whether direct or indirect, special, punitive, incidental, consequential, or otherwise), loss of prots, loss of

business, or any pecuniary loss, arising out of or related to the use of the product exceed the actual price paid for the product.

Some states do not allow the exclusion or limitation of incidental or consequential damages. If such laws apply, the limitations

or exclusions contained in this statement may not apply to you.

FR: startech.com/fr

DE: startech.com/de

ES: startech.com/es

NL: startech.com/nl

IT: startech.com/it

JP: startech.com/jp

StarTech.com

Ltd.

45 Artisans Cres

London, Ontario

N5V 5E9

Canada

StarTech.com Ltd.

Unit B, Pinnacle 15

Gowerton Rd,

Brackmills,

Northampton

NN4 7BW

United Kingdom

StarTech.com LLP

4490 South Hamilton

Road

Groveport, Ohio

43125

U.S.A.

StarTech.com Ltd.

Siriusdreef 17-27

2132 WT Hoofddorp,

The Netherlands

Regulatory Compliance

FCC -- Part 15

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC

Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.

This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the

instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not

occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be

determined by turning the equipment o and on, the user is encouraged to try to correct the interference by one or more of the

following measures:

• Connect the equipment into an outlet on a circuit dierent from that to which the receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help

This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:

(1) This device may not cause harmful interference, and (2) this device must accept any interference received, including

interference that may cause undesired operation. Changes or modications not expressly approved by StarTech.com could void

the user’s authority to operate the equipment.

Industry Canada Statement

This Class B digital apparatus complies with Canadian ICES-003.

Cet appareil numérique de la classe [B] est conforme à la norme NMB-003 du Canada.

CAN ICES-3 (B)/NMB-3(B)

This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the following two conditions:

(1) This device may not cause interference, and (2) This device must accept any interference, including interference that may

cause undesired operation of the device.

Le présent appareil est conforme aux CNR d’Industrie Canada applicables aux appareils radio exempts de licence. L’exploitation

est autorisée aux deux conditions suivantes:

(1) l’appareil ne doit pas produire de brouillage, et (2) l’utilisateur de l’appareil doit accepter tout brouillage radioélectrique subi,

même si le brouillage est susceptible d’en compromettre le fonctionnement.

IC Radiation Exposure Statement:

This equipment complies with IC RSS-102 radiation exposure limit set forth for an uncontrolled environment. This equipment

should be installed and operated with minimum distance 20cm between the radiator and your body.

This product works with devices capable of running the latest version of Chrome

OS and has been certied to meet Google’s compatibility standards. Google is

not responsible for the operation of this product or it’s compliance with safety

requirements. Chromebook and the Works With Chromebook badge are trademarks

of Google LLC.

Ce produit est compatible avec les appareils en mesure d’exécuter la dernière

version de Chrome OS et a été certié conforme aux normes de compatibilité de

Google. Chromebook et

le badge Works With Chromebook sont des marques de commerce de Google LLC.

Installation

1. Connect the Power Adapter from an AC outlet, to the DC 20V Port on the dock.

2. Connect a USB Peripheral Device to the USB-C (USB 3.2 Gen 2) Data/Charge Port on

the dock.

3. Connect a USB Peripheral Device to the USB-A (USB 3.2 Gen 2) Data/Charge Port on

the Dock.

4. Connect USB Peripheral Devices to the USB-A (USB 2.0) Data Ports, on the dock.

5. Connect USB Peripheral Devices to the USB-A (USB 3.2 Gen 2) Data Ports, located on

the Dock.

6. Connect an RJ-45 terminated network cable (CAT 5e or better) from your local area

network (e.g. Router, Switch, Modem, etc.) to the Gb Ethernet Port on the Dock, to

access your network via a wired LAN connection.

7. Video Output #1

To connect a display using the USB-C Port: If using a display with USB-C input,

connect a USB-C cable from your display to the USB-C DP Alt-Mode Video Port on

the dock.

To connect a display using the HDMI Port: Connect an HDMI cable from the HDMI

enabled display device, to the HDMI Output Port on the dock.

Requirements

• Computer

• DP Alt Mode & MST enabled USB-C Port

• Video performance, such as resolution, and refresh rate depends upon your host

computer’s video controller. Please verify the specications of your computer.

For the latest drivers, manuals, product information, technical specications, and declarations of conformance,

please visit: www.StarTech.com/DK31C3MNCR

Package Contents

• USB-C Docking Station x 1

• 3 ft (1m) USB-C Screw Lock Cable x 1

• Power Adapter x 1

To connect/charge a USB peripheral using the USB-C Port: Connect a USB-C cable

from your USB peripheral device to the USB-C Data/Charge Port on the dock.

Notes:

• The USB-C port will function for the use of USB peripherals, even if a display is

connected to the HDMI Port on Video Output 1. However, both ports cannot be

used to connect displays simultaneously.

8. Video Output #2

To connect a display using the DisplayPort or HDMI Port, connect the respective

cable from the respective port to the display device.

Note: Only a single display can be connected to either of the Video Output #2

output options.

9. Video Output #3

Connect an HDMI cable from the HDMI enabled display device, to the HDMI Output

Port on the dock.

10. Connect the 3 ft. (1m) USB-C Screw Lock Cable to the Screw-Locking USB-C Host

Port, located on the dock, and to a USB-C Port on your Host Computer. Your Host

Computer will automatically detect the dock and install the required drivers.

General Video Note: To connect other displays to any of the DisplayPort or

USB-C Video Ports, connect a USB-C or DP Video Adapter (HDMI, DisplayPort, DVI

or VGA, sold separately) from the respective port on the dock to the display device.
