TOTO CST784EF Manual
Read below ð the manual in Italian for TOTO CST784EF (32 pages) in the Toilet category. This guide has been helpful for 33 people and has been rated 4.5 stars on average by 2 users
Page 1/32
CST743ED
CST744ED
CST744EL(N)
CST744ELD
CST744EF.10
CST744EFD.10
CST754EF(N)
CST784EF
CST744EFN.10
CST243EF
CST244EF
CST423EF
CST424EF(G)
CST454CEF(G)
CST454CUF(G)
CST743E(N)
CST744E(G)(N)
CST494CEMF(G)
Warranty Registration and Inquiry
For product warranty registration, TOTO U.S.A. Inc. recommends online warranty registration. Please visit
our web site http://www.totousa.com. If you have questions regarding warranty policy or coverage, please con-
tact TOTO U.S.A. Inc., Customer Service Department, 1155 Southern Road, Morrow, GA 30260
(888) 295-8134 or (678) 466-1300 when calling from outside of U.S.A.
Installation Manual
Manual de Instrucciones
Manuel DâInstallation
2
ENGLISH
TABLE OF CONTENTS
THANKS FOR CHOOSING TOTO!
The mission of TOTO is to provide the world with healthy, hygienic and more
comfortable lifestyles. We design every product with the balance of form and
function as a guiding principle. Congratulations on your choice.
Thanks for Choosing TOTO!
.............................................................................
2
Common Tools Needed ...................................................................................... 2
Included Parts ...................................................................................................... 2
Before Installation ................................................................................................ 3
Installation Procedure .......................................................................................3-5
Toilet Tank Fill Valve Instructions .....................................................................5-6
Flush Valve Servicing Instructions .......................................................................7
Warranty................................................................................................................ 8
Rough-In Dimensions ....................................................................................... 24
Replacement Parts ............................................................................................. 25
Check to make sure you have all these parts from the package:
COMMON TOOLS NEEDED
INCLUDED PARTS
⢠10â adjustable wrench
⢠Carpenterâs Level
⢠Hacksaw
⢠Tape Measure
ADDITIONAL ITEMS (NOT SUPPLIED BY TOTO):
⢠Bowl Wax Ring
⢠Closet Flange Mounting Bolts
(usually 2 T-bolts, 2 metal washers and 2 nuts)
⢠Water Supply Line
(typically 1/2â compression to 7/8â ballcock)
⢠Toilet Seat (TOTO
SoftClose recommended)
⢠Hand Pliers
⢠Flat Screwdriver
⢠Putty Knife
China Bowl
Tank
a b
c
d
e f
Tank Lid Tank to Bowl Gasket
Tank to Bowl Hardware
a. Bolts (metal) - 2 c. Washers (metal) - 4
b. Washers (rubber) - 2 d. Nuts (metal) - 4
Flange Caps (for Bowl)
e. Caps (plastic) - 2 b. Base (plastic) - 2
Care and Cleaning
...............................................................................................7
3
ENGLISH
BEFORE INSTALLATION
ï Read these instructions thoroughly before beginning work.
ï ecnanetniam niatnoc noitcurtsni esehT .sremotsuc rof snoitcurtsni evael esaelP
and warranty information.
ï If necessary, remove the existing toilet.
INSTALLATION PROCEDURE
In order for your new TOTO toilet to ï¬t correctly, the distance between the ï¬nished
wall to the center of the closet ï¬ange must be at 10 to 12 inches. This measurement
is called the Rough-In.
egnaï¬ tesolc eht fo tuo sirbed yna naelC )1
and then install new mounting bolts
(not supplied) into the slots of the closet
ï¬ange (see Illustration 1). The head of the
bolt should be inserted into the slot with
its threads facing upward.
otno nwod edispu teliot eht nrut ylluferaC )2
some padding. Firmly press a new bowl
wax ring (not supplied) onto the circular
recess around the toilet bowlâs horn (see
Illustration 2). Turn the toilet upright and
gently lower into position over the closet
ï¬ange. With toilet properly aligned, press
ï¬rmly on both sides of toilet rim to set the
bowl wax ring (see Illustration 3).
retfa lwob eht evom ton oD :NOITU AC
the bowl wax ring is set. Thread the
nuts and tighten evenly until bowl is
snug to closet ï¬ange. Install the bolt
caps (see Illustration 3).
stun eht nethgit-revo ton oD :NOITU AC
as damage to the china bowl may
result.
Ill. 1
IMPORTANT!
Due to the powerful performance of our Cyclone, G-Max, E-Max and Power Gravity
ï¬ushing systems, they are not speciï¬ed for back-to-back installations. The only
means of installing these toilets in a back-to-back situation is when the toilet drain
connections incorporate a WYE ï¬tting. Please contact your builder or contractor prior
to this installation.
Double Combination WYE / 1/8 Bend
YES
Double Sanitary Tee / Sanitary Cross
NO
Finished
Wall
Rough-In
Closet Flange
C/L
Supply Valve
C/L
Ill. 2
Wax Ring
Horn
Bolt Cap
Nut *
Washer *
Base Cap
Bowl Base
Three Points of Contact
* Not Supplied
Ill. 3
Product Specifications
| Brand: | TOTO |
| Category: | Toilet |
| Model: | CST784EF |
