Page 1/17
1
Owner’s Manual
PRODUCT REGISTRATION
Register your product today for a
chance to win an ISOBAR
®
surge
protector in our monthly drawing!
Tripplite.Eaton.com/warranty
Este manual está disponible en español en la página de Eaton:
Tripplite.Eaton.com/support
Ce manuel est disponible en français sur le site Web de Eaton :
Tripplite.Eaton.com/support
Dieses Handbuch ist in deutscher Sprache auf der Eaton-Website verfĂĽgbar:
Tripplite.Eaton.com/support
Questo manuale è disponibile in italiano sul sito web di Eaton:
Tripplite.Eaton.com/support
Purchased product
may differ from image.
Model:
B064C-16-1-IP
NetDirector
®
16-Port Cat5 KVM
over IP Switch
2
Table of Contents
1. FCC Information 4
2. User Notice 4
3. Package Contents 4
4. Introduction 5
4.1 Overview 5
4.2 Features 6
4.3 Requirements 7
4.3.1 General 7
4.3.2 External Console 7
4.3.3 Computers 7
4.3.4 KVM Adapter Cables 7
4.3.5 Adapter Cable Resolutions 8
4.3.6 Operating Systems 8
4.4 Components 9
4.4.1 Front View 9
4.4.2 Keyboard Module 10
4.4.3 LCD Module 11
4.4.4 Rear View 12
5. Installation 13
5.1 General Safety Instructions 13
5.2 Standard Rack Mounting 15
5.3 Front-L Brackets Mounting 16
5.4 Single-Stage Installation 18
5.5 KVM Adapter Cable Installation 19
5.6 Daisy Chaining 21
6. KVM Operation 22
6.1 Basic Operation 22
6.1.1 Opening the Console 22
6.1.2 Closing the Console 25
6.2 LCD OSD Configuration 27
6.2.1 LCD Buttons 27
6.2.2 Adjustment Settings 27
6.3 Port Selection 28
6.4 Hot Plugging 28
6.4.1 Hot Plugging Console Ports 28
6.5 Powering Off and Restarting 29
6.6 Port ID Numbering 29
7. Administration 30
7.1 IP Address Determination 30
7.1.1 IPv6 31
7.1.2 Trusted Certificates 32
7.1.3 Self-Signed Private Certificates 33
7.2 OSD Operation 34
7.2.1 OSD Overview 34
7.2.2 OSD Main Screen 34
7.2.3 OSD Navigation 35
7.2.4 OSD Main Screen Headings 35
7.2.5 OSD Functions 35
7.3 Hotkey Operation 41
7.3.1 Hotkey Port Control 41
7.3.2 Invoking Hotkey Mode 41
7.3.3 Selecting the Active Port 42
7.3.4 Auto Scan Mode Switching 42
7.3.5 Skip Mode Switching 43
7.3.6 Computer Keyboard / Mouse Reset 43
7.3.7 Setting the Hotkey Beeper ON / OFF 43
7.3.8 Setting the Hotkey Key-Combination 44
7.3.9 Setting the OSD Hotkey Combination 44
7.3.10 Setting the Port Operating System 44
7.3.11 Restore the Default Values 44
7.3.12 Hotkey Summary Table 45
7.4 Keyboard Emulation 46
7.4.1 Mac Keyboard 46
7.4.2 Sun Keyboard 47
7.5 Logging In 48
7.5.1 Local Login 48
7.5.2 Browser Login 48
7.5.3 Windows Client AP Login 49
7.5.4 Java Client AP Login 51
7.6 User Interface 53
7.6.1 Web Browser Main Page 53
7.6.2 AP GUI Main Page 55
7.6.3 Control Panel 56
3
Table of Contents
7.7 Port Access 75
7.7.1 Sidebar 76
7.7.2 Filter 78
7.7.3 Connections 79
7.7.4 Favorites 80
7.7.5 User Preferences 81
7.7.6 Sessions 82
7.7.7 Access 83
7.7.8 Port Configuration 84
7.7.9 Associated Link 85
7.7.10 Occupy Timeout 85
7.8 User Management 86
7.8.1 Users 87
7.8.2 Device Assignment 90
7.9 Device Management 91
7.9.1 KVM Devices 91
7.9.2 Operating Mode 92
7.9.3 Network 93
7.9.4 ANMS 95
7.9.5 Security 98
7.9.6 Date/Time 104
7.10 Log 105
7.10.1 Log Information 106
7.11 Maintenance 107
7.11.1 Device IP Card Firmware Upgrade 108
7.11.2 Mainboard and KVM Adapter 108
Cable Firmware Upgrade
7.11.3 Recovering from Failed Firmware 110
Upgrade
7.11.4 Backup/Restore 111
7.11.5 Ping Host 112
7.11.6 System Operation 113
7.12 Download 113
7.13 Port Operation 114
7.13.1 Connecting to a Port 114
7.13.2 Port Toolbar 115
7.13.3 Panel Array Mode 117
7.13.4 Multiuser Operation 118
7.14 Log Server 119
7.14.1 Log Server Installation 119
7.14.2 Log Server Start Up 120
7.14.3 The Log Server Main Screen 123
8. Troubleshooting 125
8.1 Administration 125
8.2 General Operation 125
8.3 Windows Client 126
8.4 Java Client 127
8.5 Log Server 127
8.6 Panel Array Mode 127
8.7 Sun Systems 128
8.8 Screen Resolutions Higher than 128
1280 x 1024
8.9 Additional Mouse Synchronization 129
Procedures
8.9.1 Windows 129
8.9.2 Sun / Linux 130
8.10 Clear Login Information 131
8.11 OSD Factory Default Settings 132
9. Specications 133
10. Warranty 135
