1 947703
Issue 1
V-9910- Protection Cover (Black) BK
V-9910-YEL Protection Cover (Yellow)
INSTALLATION GUIDE
INTRODUCTION
The V-9910 (-BK, -YEL) Doorbox Weather Guard provides protection from precipitation and foreign
objects which may compromise the operation of the doorbox. It is designed for use with various Valcom
doorbox devices. The enclosure is made of steel with either a durable black or yellow powder coated
finish. The color of the enclosure can easily be changed to match any décor.
DIMENSIONS/WEIGHT
5.25” W X 5.38” H X 3.00” D
(13.335cm X 13.665cm X 7.62cm)
1.25 lbs (.056 kg)
PACKING LIST
Qty
Item
1
V-9910 (-BK, -YEL) Doorbox Weather Guard
1
VSP Document
2
Rubber Gaskets
2 947703
INSTALLATION
Note: Refer to schematic drawing on Page 1.
The V-9910 Doorbox Weather Guard is
designed for mounting on a standard double
gang electrical outlet box (not included).
Place one rubber gasket behind the Weather
Guard and place the second rubber gasket
inside the Weather Guard Insert the signal .
cable for the Doorbox Speaker through all three
pieces and connect the cable to the Door box
Speaker.
Align the screw holes in the Doorbox Speaker
with the holes in the rubber gaskets and
Weather Guard to screw holes in the double
gang outlet box, and attach with four screws.
TECHNICAL ASSISTANCE
Assistance is available from the factory when
problems are encountered. Call (540) 563-2000
and press 1 for Technical Support or visit our
website at http://www.valcom.com.
Valcom equipment is not field repairable.
Valcom, Inc. maintains service facilities in
Roanoke, VA. Should repairs be necessary,
attach a tag to the unit clearly stating company
name, address, phone number, contact person
and the nature of the problem. Send the unit to:
Valcom, Inc.
Repair and Return Dept.
5614 Hollins Road
Roanoke, VA 24019-5056
VALCOM LIMITED WARRANTY
Valcom, Inc. warrants its products to be free from defects in materials and workmanship under conditions of normal use and service
for a period of one year from the date of shipment. The obligation under this warranty shall be limited to the replacement, repair or
refund of any such defective device within the warranty period, provided that:
1. inspection by Valcom, Inc. indicates the validity of the claim;
2. the defect is not the result of damage, misuse or negligence after the original shipment;
3. the product has not been altered in any way or repaired by others and that factory sealed units are unopened (a service charge
plus parts and labor will be applied to units defaced or physically damaged);
4. freight charges for the return of products to Valcom are prepai d;
5. all units 'out of warranty' are subject to a service charge. The service charge will cover minor repairs (major repairs will be
subject to additional charges for parts and labor).
This warranty is in lieu of and excludes all other warranties, expressed or implied and in no event shall Valcom, Inc. be liable for any
anticipated profits, consequential damages, loss of time or other losses incurred by the buyer in connection with the purchase,
operation or use of the product.
This warranty specifically excludes damage incurred in shipment. In the event a product is received in damaged condition, the
carrier should be notified immediately. Claims for such damage should be filed with the carrier involved in accordance with the
F.O.B. point.
Headquarters:
Valcom, Inc.
5614 Hollins Road
Roanoke, VA 24019- 5056
Phone: (540) 563- 2000
