Page 1/17
4K UST LASER PROJECTOR
User Guide
www.vava.com
0.233
Ultra Short Throw
Made in China
NORTH AMERICA
E-mail: support@vava.com
Tel: 1-877-969-8282 (Monday-Friday: 9:00 ā 17:00 PST)
MANUFACTURER
Manufacturer: Shenzhen NearbyExpress Technology Development Co.,Ltd.
Address: 333 Bulong Road, Shenzhen, China, 518129
01-17-2020
VA-LT002_V1.0_EN
With the constant optimization of the projector, the User Guide may differ from the actual one.
CONTENTS
PACKAGE CONTENTS
PRODUCT DIAGRAM
PROJECTOR
REMOTE CONTROL
QUICK INSTALLATION GUIDE
PREPARATION
INSTALLING THE PROJECTOR
FUNCTIONS
1. MOTION DETECTION
2. MULTI-SCREEN PROJECTION
3. HDR10
4. DOLBY AUDIO AND DTS DECODING
5. TEMPERATURE PROTECTION
OPERATION GUIDE
1. POWER ON/OFF
2. POSITION ADJUSTMENT
3. USER INTERFACE OVERVIEW
4. CONNECTION WITH PERIPHERALS
5. FILE MANAGEMENT
6. SEARCHING FOR / INSTALLING / DELETING APPS
7. PAIRING VIA BLUETOOTH
8. NETWORK SETTING
9. SYSTEM UPGRADE
10. IMAGE SETTINGS
11. PLAYBACK SETTINGS
SPECIFICATIONS
CAUTIONS
1. ABOUT LASER LIGHT
2. HIGH TEMPERATURE
3. ROUTINE MAINTENANCE
FAQ
TROUBLESHOOTING
WARRANTY
CERTIFICATES
PACKAGE CONTENTS
4K UST Laser Projector (Model: VA-LT002)
Remote Control
Power Cord
AAA Battery x 2
User Guide
Cleaning Cloth
Please keep the original package properly in case of needed transportation in
the future. To protect the product, please wrap it properly as itās received.
Only use attachments/accessories speciļ¬ed by the manufacturer.
01/02
2
3
3
4
5
5
8
9
9
9
9
10
10
11
11
11
12
12
13
14
15
16
17
17
19
20
22
22
22
22
23
25
25
26
4K UST LASER PROJECTOR
User Guide
0.233
Ultra Short Throw
03/04
PRODUCT DIAGRAM
PROJECTOR
Front / Top
1. Speaker
2. Power Button
3. Status Indicator
4. PIR Sensor
5. Lens
6. Height Adjusting Wheels
7. Heat Dissipation Vents
Projector is starting / shutting off; buttons do not work
Projector disconnects from power / is working normally.
Projector connects to power but is not on.
Ā· Flashes
Ā· Off
Ā· Solid On
Forward- Lower
Backwards-
Higher
Back / Bottom
1
4
3
5
2
6
7
8. HDMI Input 1
9. HDMI Input 2
10. HDMI 3 ARC
11. USB Port
12. Audio Output
13. AV Input
REMOTE CONTROL
1
2
3
4
5
7
6
8
9
11
10
12
13
14
1. Power
2. MIC
3. Mute
4. Up
5. Left
6. Right
7. OK
8. Down
9. Return
10. Home
11. Menu
12. Volume -
13. Volume +
14. AAA Battery Holder
1) Press Return and Menu buttons at the same time for Bluetooth pairing.
2) During video playing, press Menu button to enter the Menu interface;
otherwise, press and hold the button to enter the interface.
3) MIC function is not available for now and reserved for future use.
4) 2 AAA batteries are required for the Bluetooth remote control.
Side
8 10
9
11 12 13 14 15
18
16
19
17
14. S/PDIF Port
15. Ethernet Port
16. Power Port
17. Rear Foot
18. Speaker Air Vents
19. Front Foot x 2
Forward- Higher
Backwards-
Lower
