Thank you for choosing Watson Pro
Please read this user manual carefully and keep
it for reference before using the charger.
C-AM-2C
C-VM-2C
Dual Position Compact
Li-ion Battery Charger
TM
ATTACHING AND CHARGING A BATTERY
1. Place the charger on a flat surface.
2. Use the included AC power cable to connect the charger to a power source.
3. Align the battery's V-mount or Gold mount with the battery mount in the charger.
4. Slide the battery into the plate until it clicks.
5. Flip the charger's power switch to the On position.
The charger will recognize when a battery is connected to Channel 1 or 2. The charger
will simultaneously output 3 A per channel.
1. Battery mount
1. Charging indicators
1. Power switch
1. Cooling vents
2. Battery release latch
3. AC power input
AC Input
100–240 V
OVERVIEW
1
1
4
1
4
6
5
5
4
3 6
3
2 5
2
RELEASING THE BATTERY FROM THE CHARGER
1. Press and hold the battery release latch.
2. Slide the battery out from the charger slots, and separate it from the
charging plate.
2
3
4
5
1
2
STATUS INDICATORS
Off • The charger is turned off.
Red • The batteries are charging.
Green
• The charger is connected to a power source.
• The batteries are fully charged.
Flashing Light
The charger has detected a defective battery. For more
information, or to arrange service, visit
www.poweredbywatson.com or call Watson Customer Service
at 212-594-2120.
SAFETY INSTRUCTIONS
 Do not store, place, or use the charger where it may come into contact with excess heat,
water, or moisture.
 High-voltage internal components present the risk of electrical shock.
 Charge only at room temperature on a dry, vibration-free surface.
 Should you ever notice smoke or a strange odor coming out of the charger, immediately
unplug the AC adapter from the power outlet. Using the charger under these conditions
can cause fire and electric shock.
 Do not short-circuit the terminals of your battery or charger.
 Do not attempt to disassemble any part of the charger.
 The charger, adapters, and batteries may feel warm during the charging process. This is
normal.
 Remove any battery after it is fully charged.
 Unplug the AC cable from the power outlet and clean the area around the prongs of the
plug when necessary. The presence of dust around the prongs can cause fire.
 All images are for illustrative purposes only.
SPECIFICATIONS
AC input 100–240 V, 47–63 Hz
Power Source AC power (cable included)
Input Power 100–240 V, 50–60 Hz
Output Charging Power 16.8 V, 3A (×2)
Compatible Li-ion Battery Mounts
V-mount (C-VM-2C)
Gold-mount (C-AM-2C)
Number of Bays 2
Multi-Bay Charging Mode Simultaneous
Indicator LED
Operating Temperature -13°F–122°F (-25°C–50°C)
Dimensions (L × W × H)
4.6 × 4.6 × 7.1 in.
(117 × 117 × 180 mm)
Weight 1.8 lb. (834 g)
