Page 1/14
User
Manual
WGen20000TFc
Portable Generator
DO NOT RETURN THIS PRODUCT TO THE STORE
If you have questions or need assistance, please call customer service at 855-944-3571.
2 | English
TABLE OF CONTENTS
Introduction ............................................................................................................................................................................. 2-3
Safety
...................................................................................................................................................................................4-11
Electrical
.................................................................................................................................................................................. 12
Components
.......................................................................................................................................................................13-15
Assembly
............................................................................................................................................................................16-17
Operation
............................................................................................................................................................................ 18-27
Maintenance
.......................................................................................................................................................................28-35
Troubleshooting
.......................................................................................................................................................................36
Schematics
.............................................................................................................................................................................. 37
Service Hotline/Company Address
.............................................................................................................................Back Page
INTRODUCTION
WARNING
Operating, servicing, and main-
taining this equipment can expose you to chemicals in-
cluding engine exhaust, carbon monoxide, phthalates,
and lead, which are known to the State of California
to cause cancer and birth defects or other reproduc-
tive harm. To minimize exposure, avoid breathing ex-
haust, and wear gloves or wash your hands frequently
when servicing this equipment. For more information
go to www.P65warnings.ca.gov.
DISCLAIMERS
All information, illustrations, and speciî·”cations in this man-
ual were in effect at the time of publishing. The illustrations
used in this manual are intended as representative reference
views only. We reserve the right to make any speciî·”cation
or design change without notice.
ALL RIGHTS RESERVED
All rights reserved. No reproduction allowed in any form
without written permission from Westinghouse Outdoor
Power Equipment.
DANGER
Read this manual before
using or performing maintenance on this prod-
uct. Failure to follow the instructions and safety
precautions in this manual can result in serious
injury or death.
UPDATES
The latest User Manual for your Westinghouse products
can be found under our support tab. wpowereq.com/
pages/manuals
Or scan the following QR code with your smartphone cam-
era to be directed to the link.
PRODUCT REGISTRATION
For trouble-free warranty coverage, it
is important to register your Westing-
house product.
You can register by:
l Completing and mailing the product
registration card included in the car-
ton.
l Registering your product on-line at: wpowereq.com/
pages/warranty-registration
l
Scanning the above QR code with your smartphone
camera to be directed to the mobile registration link.
For Your Records
Date of Purchase:
Model Number:
Serial Number:
Place of Purchase:
l Sending the following product information to:
Westinghouse Outdoor Power
Warranty registration
777 Manor Park Drive
Columbus, OH 43228
IMPORTANT: Keep your purchase receipt for trouble-free
warranty coverage.
English | 3
INTRODUCTION
SPECIFICATIONS
AC Voltage........................................................120V/240V
Power (Running).................................20000W (Gasoline),
18000W (Propane),16000W (Natural Gas)
Power (Peak)
......................................28000W (Gasoline),
25200W (Propane), 22400W (Natural Gas)
AC Current..........................................166/83A (Gasoline),
150/75A (Propane),
133.4/66.7A (Natural Gas)
Frequency.......................................... 60 Hz @ 3600 RPM
Phase
.......................................................................Single
RPM
............................................................................3600
Power Factor
.................................................................1.0
Insulation Class
...............................................................H
Maximum Ambient Temperature
................... 104°F (40°C)
Fuel Type
.................... Unleaded gasoline (87–93 Octane)
Do not use E15 or E85 fuel in this product.
Fuel Capacity..................................17 gallons (64.3 liters)
Oil Capacity
.....................................2.3 quarts (2.18 liters)
Oil Type
.........................................................SAE 10W-30
Spark Plug
.............................................97110 (GAS5357)
Spark Plug Gap
.......... 0.024 – 0.032 in. (0.65 – 0.75 mm)
Valve Intake Clearance
........................0.0031 – 0.0047 in.
(0.08 – 0.12 mm)
Valve Exhaust Clearance
....................0.0051 – 0.0067 in.
(0.13 – 0.17 mm)
AC Grounding System
.............................Bonded to frame
NOTICE
The effect of altitude on horsepower will
be greater if no carburetor modiî·”cation is made. A de-
crease in engine horsepower will decrease the power
output of the generator. Contact our service team to
order altitude kits.
NOTICE
Thank you for choosing Westinghouse!
PLEASE READ BEFORE RETURNING THIS PROD-
UCT FOR ANY REASON.
If you have a question or experience a problem with your
Westinghouse purchase, call us at 1-855-944-3571 to
speak with an agent.
SAVE THIS MANUAL FOR FUTURE REFERENCE.
NOTICE
This product is designed and rated for
continuous operation at ambient temperatures be-
tween 23°F (–5°C) and 104°F (40°C). If needed, this
product can be operated in extremely hot or extremely
cold temperatures for short periods. If the product is
exposed to extreme temperatures during storage, it
should be brought back within the optimal tempera-
ture range before operation. This product must always
be operated outdoors in a well-ventilated area and far
away from doors, windows, and other vents.
Maximum wattage and current are subject to and
limited by such factors as fuel BTU content, ambient
temperature, altitude, engine conditions, etc. Maxi-
mum power decreases about 3.5% for each 1,000 feet
above sea level, and will also decrease about 1% for
each 10°F (6°C) above 60°F (16°C) ambient tempera-
ture.
HAVE QUESTIONS?
Email us at service@wpowereq.com
or call 1-855-944-3571
