Page 1/2
EN
Quick guide
1
PRODUCT DESCRIPTION
CONTROL PANEL
1. Control panel
2. Upper heating element/grill
3. Cooling system
(if present)
4. Dataplate
(not to be removed)
5. Light
6. Baking ventilation system
(if present)
7. Turnspit
(if present)
8. Lower heating element
(not visible)
9. Door
10. Position of shelves
11. Rear wall
1. SELECTION KNOB
For switching the oven on by
selecting a function.
Turn to the
position to switch
the oven off.
2. +/- BUTTON
To decrease or increase the value
shown on the display.
3. TIME BUTTON
For
selecting the various settings:
duration, timer.
4. DISPLAY
5. THERMOSTAT KNOB
Turn to select the temperature you
require.
6. LED THERMOSTAT/
PREHEATING
Switches on during the heating
process. Switches off once the
desired temperature is reached.
Please note: All knobs are push-
activated knobs. Push down on the
centre of the knob to release it from its
seating.
1
11
5
2
4
7
8
10
9
6
3
1 32 2 5
6
4
THANK YOU FOR BUYING A WHIRLPOOL
PRODUCT
In order to receive a more complete
assistance, please register your product
on www . whirlpool . eu/ register
Before using the appliance carefully read the
Safety Instruction.
2
ACCESSORIES
WIRE SHELF DRIP TRAY (IF PRESENT) BAKING TRAY
SLIDING RUNNERS
(IF PRESENT)
The number and the type of accessories may vary depending on which model is purchased.
Other accessories can be purchased separately from the After-sales Service.
USING THE ACCESSORIES
• Insert the wire shelf onto the level you require by
holding it tilted slightly upwards and resting the raised
rear side (pointing upwards) down rst. Then slide it
horizontally along the shelf guide as far as possible.
The other accessories, such as the baking tray, are
inserted horizontally by sliding them along the shelf
guides.
FUNCTIONS
OFF
To stop cooking and switch off the oven.
LAMP
To switch the oven light on/off.
CONVENTIONAL
To cook any kind of dish on one shelf only.
Use the 2nd shelf. Preheat the oven to the required
temperature. The thermostat led turns off when the
oven is ready and food can be placed in it.
CONVECTION BAKE
For baking cakes with liquid lling (sweet or
savoury) on a single shelf. This function can also be
used for cooking on two shelves. Switch the position of
the dishes to cook food more evenly. Use the 2nd shelf
to cook on one shelf only, and the 2nd and 4th to cook
on two shelves. Preheat the oven before cooking.
GRILL
To grill steak, kebabs and sausages; to cook
vegetables au gratin and toast bread. Place food on the
4th shelf. When grilling meat, use the drip tray to collect
the cooking juices. Position it on the 3rd shelf, adding
approx. half a litre of water. Preheat the oven f or 3-5
min. During cooking the oven door must remain closed.
TURBO GRILL
To roast large joints of meat (legs, roast beef,
chickens). Position the food on the middle shelves.
Use the drip tray to collect the cooking juices.
Position it on the 1st/2nd shelf, adding approx. half
a litre of water. It is advisable to turn the meat over
during cooking for more even browning. The oven
does not have to be preheated. During cooking the
oven door must remain closed.
DEFROST
To speed up defrosting of food. Place food on
the middle shelf. Leave food in its packaging in order
to prevent it from drying out on the outside.
BOTTOM + CONVECTION BAKE
For cooking fruit, cakes, vegetables, pizza,
poultry, etc. on a single level.
FORCED AIR
Also to cook different types of food requiring
the same cooking temperature (e.g. fish, vegetables,
cakes) on a maximum of two shelves at the same
time. This function allows cooking without odours
being transferred from one food to another. It is
advisable to use the 2nd level to cook on a single
shelf. To cook on two shelves, it is advisable use the
1st and 3rd levels, preheating the oven first.
BOTTOM
Use this function after cooking to brown the
bottom of the dish. It is advisable to place the food
on the 1st /2nd cooking level. The function can also
be used for slow cooking, such as vegetables and
meat stews; in this case use the 2nd cooking level.
The oven does not have to be preheated.
Product Specifications
| Brand: | Whirlpool |
| Category: | Oven |
| Model: | AKP 462/IX |
