SAFETY INSTRUCTIONS

IMPORTANT TO BE READ AND OBSERVED

Download the complete instruction manual on http://

docs.whirlpool.eu or call the phone number shown

on the warranty booklet.

Before using the appliance, read these safety instructions.

Keep them nearby for future reference.

These instructions and the appliance itself provide

important safety warnings, to be observed at all times.

The manufacturer declines any liability for failure to

observe these safety instructions, for inappropriate use

of the appliance or incorrect setting of controls.

WARNING: If the hob surface is cracked, do not use

the appliance - risk of electric shock.

WARNING: Danger of re: Do not store items on the

cooking surfaces.

CAUTION: The cooking process has to be supervised. A

short cooking process has to be supervised continuously.

WARNING: Unattended cooking on a hob with fat or

oil can be dangerous - risk of re. NEVER try to extinguish

a re with water: instead, switch o the appliance and

then cover ame e.g. with a lid or a re blanket.

Do not use the hob as a work surface or support.

Keep clothes or other ammable materials away from

the appliance, until all the components have cooled

down completely - risk of re.

Very young children (0-3 years) should be kept away

from the appliance. Young children (3-8years) should be

kept away from the appliance unless continuously

supervised. Children from 8 years old and above and

persons with reduced physical, sensory or mental

capabilities or lack of experience and knowledge can use

this appliance only if they are supervised or have been

given instructions on safe use and understand the

hazards involved. Children must not play with the

appliance. Cleaning and user maintenance must not be

carried out by children without supervision.

WARNING: The appliance and its accessible parts

become hot during use. Care should be taken to avoid

touching heating elements. Children less than 8 years of

age shall be kept away unless continuously supervised.

PERMITTED USE

CAUTION: the appliance is not intended to be

operated by means of an external switching device,

such as a timer, or separate remote controlled system.

This appliance is intended to be used in household

and similar applications such as: sta kitchen areas in

shops, oces and other working environments; farm

houses; by clients in hotels, motels, bed & breakfast

and other residential environments.

No other use is permitted (e.g. heating rooms).

This appliance is not for professional use. Do not use

the appliance outdoors.

INSTALLATION

The appliance must be handled and installed by two

or more persons - risk of injury. Use protective gloves to

unpack and install - risk of cuts.

Installation, including water supply (if any), electrical

connections and repairs must be carried out by a qualified

technician. Do not repair or replace any part of the appliance

unless specifically stated in the user manual. Keep children

away from the installation site. After unpacking the

appliance, make sure that it has not been damaged during

transport. In the event of problems, contact the dealer or

your nearest After-sales Service. Once installed, packaging

waste (plastic, styrofoam parts etc.) must be stored out of

reach of children - risk of suffocation. The appliance must

be disconnected from the power supply before any

installation operation - risk of electric shock. During

installation, make sure the appliance does not damage the

power cable - risk of fire or electric shock. Only activate the

appliance when the installation has been completed.

Carry out all cabinet cutting operations before tting

the appliance and remove all wood chips and sawdust.

If the appliance is not installed above an oven, a

separator panel (not included) must be installed in the

compartment under the appliance.

ELECTRICAL WARNINGS

It must be possible to disconnect the appliance from the

power supply by unplugging it if plug is accessible, or by a

multi-pole switch installed upstream of the socket in

accordance with the wiring rules and the appliance must

be earthed in conformity with national electrical safety

standards.

Do not use extension leads, multiple sockets or adapters.

The electrical components must not be accessible to the

user after installation. Do not use the appliance when you

are wet or barefoot. Do not operate this appliance if it has a

damaged power cable or plug, if it is not working properly,

or if it has been damaged or dropped.

Installation using a power cable plug is not allowed

unless the product is already equipped with the one

provided by the Manufacturer.

If the supply cord is damaged, it must be replaced

with an identical one by the manufacturer, its service

agent or similarly qualied persons in order to avoid a

hazard - risk of electric shock.

CLEANING AND MAINTENANCE

WARNING: Ensure that the appliance is switched o

and disconnected from the power supply before

performing any maintenance operation; never use

steam cleaning equipment - risk of electric shock.

Do not use abrasive or corrosive products, chlorine-

based cleaners or pan scourers.

DISPOSAL OF PACKAGING MATERIALS

The packaging material is 100% recyclable and is marked with the recycle

symbol

The various parts of the packaging must therefore be disposed of responsibly

and in full compliance with local authority regulations governing waste

disposal.

DISPOSAL OF HOUSEHOLD APPLIANCES

This appliance is manufactured with recyclable or reusable materials.

Dispose of it in accordance with local waste disposal regulations. For further

information on the treatment, recovery and recycling of household electrical

appliances, contact your local authority, the collection service for household

waste or the store where you purchased the appliance. This appliance is

marked in compliance with European Directive 2012/19/EU, Waste Electrical

and Electronic Equipment (WEEE) and with the Waste Electrical and Electronic

Equipment regulations 2013 (as amended).

By ensuring this product is disposed of correctly, you will help prevent

negative consequences for the environment and human health.

The symbol

on the product or on the accompanying documentation

indicates that it should not be treated as domestic waste but must be taken to

an appropriate collection center for the recycling of electrical and electronic

equipment.

ENERGY SAVING TIPS

Make the most of your hot plate’s residual heat by switching it o a few

minutes before you nish cooking.

The base of your pot or pan should cover the hot plate completely; a container

that is smaller than the hot plate will cause energy to be wasted.

Cover your pots and pans with tight-tting lids while cooking and use as

little water as possible. Cooking with the lid o will greatly increase energy

consumption.

Use only at-bottomed pots and pans.

DECLARATION OF CONFORMITY

This appliance meets Ecodesign requirements of European Regulation

66/2014 and The Ecodesign for Energy-Related Products and Energy

Information (Amendment) (EU Exit) Regulations 2019 in compliance with the

European standard EN 60350-2.

INSTALLATION

• The cooktop must be set into a worktop at least 20 mm deep.

• There must be nothing between the cooktop and the oven (cross rails, brackets, etc.).

• Make sure the power cord is long enough to allow convenient installation.

• The distance between the lower face of the glass ceramic hob and the cupboard or separating

panel must be at least 20 mm.

• For built-in dimensions and installation see the picture in this paragraph.

• A minimum distance must be maintained between the hob and the hood above it. Please refer to the

user manual of the hood for more informations.

• Apply the supplied gasket to the cooktop (unless it has already been tted), after having cleaned its surface.

• Do not install the cooktop near a dishwasher or washing machine, so that the electronic circuits do not come into contact with steam or

moisture, which could damage them.

• If an oven (from our range of ovens) is installed beneath the cooktop, make sure that it is equipped with a cooling system. If the temperature of the

electronic circuits exceeds the maximum permitted temperature, the cooktop will switch o automatically; in this case, wait for a few minutes until the

internal temperature of the electronic circuits reaches a tolerable level, at which point it will be possible to switch the hob on again.

PLACING THE HOB

After the electrical connection (see the chapter “Electrical connection“).Position each xing clips on the dedicated slots on the lateral sides of the hob as

shown in the picture. Then push the hob inside the cut out and check that the glass is at and parallel to the worktop. The xing clips are designed for

every type of worktop material (wood, marble, etc).

DIMENSIONS AND DISTANCES TO BE MAINTAINED

Min. 40 cm

Min. 5 cm

Min.10 cm

552 mm

42 mm

510 mm

580 mm

Min. 6,5 mm

Max. 8 mm

490 - 492 mm

560 - 562 mm

Min. 50 mm

Min.

20 mm

482 mm

REMOVING THE HOB:

To remove the hob, rst, disconnect it from the electric supply. It is strongly recommended to free the underneath part from the oven, drawer, separator, or other.

It allows the technician to access the lower part of the hob to unfasten the four clips with a screwdriver, lift the hob and remove it, avoiding any worktop damage.

min. 20 mm
