Page 1/8
EN
Quick guide
THANK YOU FOR BUYING A WHIRLPOOL PRODUCT
In order to receive a more complete assistance, please
register your product on www . whirlpool . eu/ register
Before using the appliance carefully read the Safety
Instruction.
PRODUCT DESCRIPTION
FIRST TIME USE
Wait at least two hours, after the installation, before connecting the
appliance to the power supply.
Connect the appliance to the power supply and turn the thermostat
knob to switch on the appliance.
After turning the appliance on, you must wait for 4-6 hours for the
correct storage temperature to be reached for a normally îlled
appliance. Position the antibacterial anti-odour îlter in the fan as
demonstrated in the îlter packaging (if available).
CONTROL PANEL
1. On/standby
2. Temperature display
3. Fast cool button
4. Alarm indicator
5. Temperature button
6. 6th sense fresh control
4.
5.
1.
3.2.6.
ON/STANDBY
To put the product in Stand-by, press and hold the button
for 3
seconds. All the icons turn oî except On/Standby indicator
. To
reactivate the appliance press once (brieîy) this button (seeîthe
Instructions for Use).
FAST COOL BUTTON
Using Fast Cool function it is possible to increase the cooling
capacity in the refrigerator compartment. The use of this function
is recommended when placing a very high quantity of food in the
refrigerator compartment. Press the Fast Cool button
to activate
Fast Cool function. When activated, the Fast Cool indicator turns on.
The function is automatically disabled after 6 hours, or can be manually
disabled by pressing Fast Cool button
again.
STOP ALARM BUTTON
Press in case of alarm to mute the acoustic alarm.
TEMPERATURE BUTTON
Press the temperature button
to change the temperature: theîvalue
changes cyclically between 8°C ad 2°C.
Note: Displayed set points correspond to the average temperature
throughout the whole refrigerator.
6TH SENSE FRESH CONTROL
This function automatically works to ensure the optimal conditions to
preserve the stored food. To deactivate the â6thîSense Fresh Controlâ,
press and hold Fast Cool
and Stop Alarm buttons at the same
time for 3îseconds until an audible signal sounds and â6th Sense Fresh
Controlâ icon
turns oî as conîrmation that the feature has been
deactivated. To reactivate this function repeat the same procedure.
Note: Deactivation of the function switch-oî the FAN in the fridge.
FAN
The Fan improves temperature distribution inside the product,
allowing better preservation of stored food. By default, the fan is
switched on. To switch oî the FAN press and hold Fast Cool
and
Stop alarm
buttons at the same time for 3 seconds until an audible
signal sounds and â6
th
Sense Fresh Controlâ icon will turn oî as
conîrmation that the fan has been switched oî. To switch on the FAN
repeat the same procedure. As a conîrmation audible signal sounds
and the icon turns on.
Note: Reasons why switch oî the fan look for âENERGY-SAVING TIPSâ in the
Instructions for Use.
VACATION BUTTON
This function can be activated to reduce the energy consumption of
the appliance during a prolonged period of time.
Before activating the feature, all perishable food should be removed
from the refrigeration compartment and make sure that the door
is closed properly, since the refrigerator will maintain aîsuitable
temperature to prevent the formation of unpleasant odors (+12°C). To
activate/ deactivate press the Vacation mode button for 3 seconds.
When the function is enabled, the related symbol will light up
and the temperature of the refrigerator compartment will be set
to a higher setpoint (theîtemperature display will show the new
temperature setpoint of +12°C). Changing the temperature setpoint
will automatically deactivate the function.
HOW TO STORE FOOD AND BEVERAGE
X X
Legend
FREEZER ZONE
TEMPERATE ZONE
Suggested for the storage of tropical fruit, cans, drinks,
eggs, sauces, pickles, butter, jam
COOL ZONE
Suggested for the storage of cheese, milk, daily food,
delicatessen, yogurt
COOLEST ZONE
Suggested for the storage of cold cuts, desserts, îsh and
meat
FRUIT & VEGETABLE DRAWER
ZERO DEGREES DRAWER*
The Zero Degrees Drawer is speciîcally designed to maintain a low
temperature and a suitable humidity level, in order to keep foods
fresher for longer (e.g. meat, îsh, fruit and winter vegetables).
ACTIVATING AND DEACTIVATING THE BOX
To activate / deactivate the box, press the
button as illustrated in the îgure.
When the box has been activated, the
symbol lights up.
The temperature inside the box, when active, is approximately 0°. The
following factors are vital for the âZero Degreesâ box to work properly:
⢠the refrigerator compartment must be switched on
⢠the temperature of the refrigerator compartment must be
between +2°C and +5°C
⢠the box must be inserted to enable activation
⢠no special functions must have been selected (Standby, Vacation â
where applicable).
If one of these special functions has been selected, the âZero Degreesâ
box must be deactivated manually, and any fresh food inside it
removed. If manual deactivation does not take place, the box will be
deactivated automatically after 8 hours.
Note:
- if the symbol does not light up when the function is activated, check
that the drawer is properly inserted; if the problem persists, contact
your nearest authorized After-sales Service
- if the function is active and the drawer open, the symbol on the
control panel may be deactivated automatically. If the drawer is
inserted, the symbol will become active again
- irrespective of the state of the function, a slight noise may be heard:
this is normal and is not a cause for concern.
- when the function is not active, the temperature in the drawer
depends on the general temperature inside the refrigerator.
In this case, we recommend it is used to store fruit and vegetables which
are not sensitive to cold temperatures (fruits of the forest, apples, apricots,
carrots, spinach, lettuce, etc.).
Important: when the function is activated and there are foodstuîs
with a high water content, condensation may form on shelves. In this
case, disable the function temporarily.
*Available on selected models only. Please check on the QUICK START GUIDE if this function is actually available on your model.
TROUBLESHOOTING
What to do if... Possible reasons Solutions
The appliance doesnât work. There may be an appliance power
supply problem.
Make sure:
⢠there is not a power failure;
⢠the plug is properly inserted in the power socket and the double-
pole switch (if present) is in the correct position (on);
⢠the household electrical system protection devices function;
⢠the power cable is not broken;
The inside light does not
work.
It may be necessary to replace the light
bulb.
Disconnect the appliance from the power supply and contact the
Technical Assistance Service if you need a replacement.
The internal temperature
of the compartments is not
cold enough.
The reasons could vary (see âSolutionâ)
column.
Check that:
⢠the doors are closed properly;
⢠the appliance is not installed near a heat source;
⢠the temperature is appropriately set;
⢠the circulation of air through the ventilation grilles on the base of
the appliance is not obstructed.
There is water on the
bottom of the refrigerator
compartment.
The defrost water drain is blocked. Clean the defrosting water drain (see section âCleaning and
Maintenance").
The front edge of the
appliance that the door
gaskets seal against is hot.
This is not a problem. It prevents
condensation from forming.
A solution is not needed.
The temperature of the
refrigerator compartment is
too cold.
⢠The set temperature is too cold. ⢠Try to set a less cold temperature.
⢠Turn oî the fan (if present) described in the paragraph âFANâ.
You can download the Safety Instructions, User Manual, Product Fiche and Energy data by:
⢠Visiting our website docs . whirlpool . eu
⢠Using QR Code
⢠Alternatively, contact our After-sales Service (See phone number in the warranty booklet). When
contacting our After-sales Service, please state the codes provided on your product's identiîcation
plate.
Product Specifications
| Brand: | Whirlpool |
| Category: | Refrigerator |
| Model: | SW8 AM2C XRL 2 |
