Page 1/25
THANK YOU for purchasing this high-quality product. Register your new refrigerator at www.whirlpool.com. In Canada, register
your refrigerator at www.whirlpool.ca.
For future reference, please make a note of your product model and serial numbers. These can be located on the inside wall
of
the refrigerator compartment.
Model Number__________________________________________________ Serial Number __________________________________________________
REFRIGERATOR
USER INSTRUCTIONS
Table of Contents / Índice / Table des matières
REFRIGERATOR SAFETY.................................2
INSTALLATION INSTRUCTIONS ..................... 3
Unpack the Refrigerator .................................3
Location Requirements................................... 3
Remove and Replace Refrigerator
Doors
and Drawer Front ................................. 4
Electrical Requirements..................................8
Water Supply Requirements...........................8
Connect the Water Supply .............................8
Handle Installation and Removal..................10
Door Closing and Door Alignment................11
FILTERS AND ACCESSORIES .......................11
Water Filtration System.................................11
Install Air Filter............................................... 12
Install Produce Preserver..............................12
Accessories...................................................13
REFRIGERATOR USE .....................................13
Opening and Closing Doors .........................13
Using the Controls ........................................13
Water Dispenser ...........................................15
Ice Maker ......................................................16
REFRIGERATOR FEATURES .........................16
Refrigerator Shelves...................................... 17
Pantry Drawer ...............................................17
Crisper...........................................................17
DOOR FEATURES ...........................................18
Condiment Bins ............................................18
Fresh Bin .......................................................18
Half-Height Bin..............................................18
REFRIGERATOR CARE ..................................19
Cleaning ........................................................19
Changing the Light Bulbs .............................19
TROUBLESHOOTING .....................................20
Operation ...................................................... 20
Noise .............................................................21
Temperature and Moisture ........................... 22
Ice and Water................................................23
Doors.............................................................25
PERFORMANCE DATA SHEET......................26
WARRANTY......................................................27
SEGURIDAD DEL REFRIGERADOR.............. 28
INSTRUCCIONES DE INSTALACIÓN............ 29
Desempaque el refrigerador......................... 29
Requisitos de ubicación............................... 30
Cómo sacar y volver a colocar las puertas
y el frente del cajón del refrigerador............. 30
Requisitos eléctricos .................................... 34
Requisitos del suministro de agua............... 34
Conexión del suministro de agua................. 34
Instalación y remoción de las manijas ......... 36
Cierre y alineamiento de las puertas............ 37
FILTROS Y ACCESORIOS.............................. 38
Sistema de filtración de agua....................... 38
Instalación del filtro de aire........................... 38
Instalación del preservador
de alimentos frescos .................................... 39
Accesorios.................................................... 40
USO DE SU REFRIGERADOR........................ 40
Cómo abrir y cerrar las puertas.................... 40
Uso de los controles..................................... 40
Despachador de agua.................................. 42
Fábrica de hielo ............................................ 43
CARACTERÍSTICAS DEL
REFRIGERADOR............................................. 44
Estantes del refrigerador .............................. 44
Cajón-despensa ........................................... 44
Cajón para verduras ..................................... 45
CARACTERÍSTICAS DE LA PUERTA............ 45
Recipientes para condimento ...................... 45
Recipiente para productos frescos.............. 45
Recipiente de altura media........................... 46
CUIDADO DE SU REFRIGERADOR .............. 46
Limpieza........................................................ 46
Cómo cambiar los focos .............................. 46
SOLUCIÓN DE PROBLEMAS ........................ 47
Funcionamiento............................................ 47
Ruido............................................................. 48
Temperatura y humedad.............................. 49
Hielo y agua.................................................. 50
Puertas.......................................................... 52
HOJA DE DATOS DEL RENDIMIENTO......... 53
GARANTÍA ....................................................... 54
SÉCURITÉ DU RÉFRIGÉRATEUR..................55
INSTRUCTIONS D’INSTALLATION................56
Déballage du réfrigérateur ............................56
Exigences d’emplacement............................57
Retrait et réinstallation des portes
du
réfrigérateur et de l’avant du tiroir ...........57
Spécifications électriques.............................61
Spécifications de l’alimentation en eau........61
Raccordement à l’alimentation en eau.........61
Installation et démontage des poignées.......63
Fermeture et alignement de la porte.............64
FILTRES ET ACCESSOIRES...........................65
Système de filtration de l’eau .......................65
Installation du filtre à air ................................65
Installation du conservateur pour
produits frais .................................................66
Accessoires...................................................67
UTILISATION DU RÉFRIGÉRATEUR .............67
Ouverture et fermeture des portes ...............67
Utilisation des commandes ..........................67
Distributeur d’eau..........................................69
Machine à glaçons........................................70
CARACTÉRISTIQUES DU
RÉFRIGÉRATEUR............................................71
Tablettes du réfrigérateur..............................71
Garde-manger...............................................71
Bac à légumes...............................................72
CARACTÉRISTIQUES DE LA PORTE............72
Balconnets à condiments .............................72
Balconnet fraîcheur.......................................72
Balconnet mi-hauteur....................................73
ENTRETIEN DU RÉFRIGÉRATEUR ...............73
Nettoyage......................................................73
Remplacement des ampoules d’éclairage ...74
DÉPANNAGE....................................................75
Fonctionnement ............................................75
Bruit ...............................................................76
Température et humidité...............................77
Glaçons et eau ..............................................78
Portes ............................................................80
FEUILLE DE DONNÉES SUR LA
PERFORMANCE..............................................81
GARANTIE........................................................82
W10400960C
2
REFRIGERATOR SAFETY
Proper Disposal of
Your
Old Refrigerator
IMPORTANT: Child entrapment and suffocation are not problems
of the past. Junked or abandoned refrigerators are still dangerous –
even if they will sit for “just a few days.” If you are getting rid
of
your old refrigerator, please follow these instructions to help
prevent accidents.
Before You Throw Away Your Old Refrigerator or Freezer:
■ Take off the doors.
■ Leave the shelves in place so that children may not easily
climb
inside.
You can be killed or seriously injured if you don't immediately
You
can be killed or seriously injured if you don't
follow
All safety messages will tell you what the potential hazard is, tell you how to reduce the chance of injury, and tell you what can
happen if the instructions are not followed.
Your safety and the safety of others are very important.
We have provided many important safety messages in this manual and on your appliance. Always read and obey all safety
messages.
This is the safety alert symbol.
This symbol alerts you to potential hazards that can kill or hurt you and others.
All safety messages will follow the safety alert symbol and either the word “DANGER” or “WARNING.”
These words mean:
follow instructions.
instructions.
DANGER
WARNING
IMPORTANT SAFETY INSTRUCTIONS
WARNING:
To reduce the risk of fire, electric shock, or injury when using your refrigerator, follow these basic precautions:
SAVE THESE INSTRUCTIONS
■ Plug into a grounded 3 prong outlet.
■ Do not remove ground prong.
■ Do not use an adapter.
■ Do not use an extension cord.
■ Disconnect power before servicing.
■ Replace all parts and panels before operating.
■ Remove doors from your old refrigerator.
■ Use nonflammable cleaner.
■ Keep flammable materials and vapors, such as gasoline,
away from refrigerator.
■ Use two or more people to move and install refrigerator.
■ Disconnect power before installing ice maker (on ice maker
kit ready models only).
■ Use a sturdy glass when dispensing ice (on some models).
■ Do not hit the refrigerator glass doors (on some models).
State of California Proposition 65 Warnings:
WARNING: This product contains one or more chemicals known to the State of California to cause cancer.
WARNING: This product contains one or more chemicals known to the State of California to cause birth defects or other
reproductive harm.
WARNING
Suffocation Hazard
Remove doors from your old refrigerator.
Failure to do so can result in death or brain damage.
Important information to know about disposal of
refrigerants:
Dispose of refrigerator in accordance with Federal and Local
regulations. Refrigerants must be evacuated by a licensed,
EPA certified refrigerant technician in accordance with
established procedures.
3
INSTALLATION INSTRUCTIONS
Unpack the Refrigerator
Remove the Packaging
■ Remove tape and glue residue from surfaces before turning
on
the refrigerator. Rub a small amount of liquid dish soap over
the adhesive with your fingers. Wipe with warm water and dry.
■ Do not use sharp instruments, rubbing alcohol, flammable
fluids, or abrasive cleaners to remove tape or glue. These
products can damage the surface of your refrigerator. For
more
information, see “Refrigerator Safety.”
■ Dispose of/recycle all packaging materials.
Clean Before Using
After you remove all of the packaging materials, clean the inside
of
your refrigerator before using it. See the cleaning instructions
in
“Refrigerator Care.”
Location Requirements
To ensure proper ventilation for your refrigerator, allow for a
¹⁄₂"
(1.25 cm) of space on each side and at the top. Allow for
a
1" (2.54 cm) space behind the refrigerator. If your refrigerator
has
an ice maker, allow extra space at the back for the water line
connections. When installing your refrigerator next to a fixed wall,
leave a 2" (5.08 cm) minimum space between the refrigerator and
wall to allow the door to swing open.
NOTE: This refrigerator is intended for use in a location where
the
temperature ranges from a minimum of 55°F (13°C) to a
maximum of 110°F (43°C). The preferred room temperature range
for optimum performance, which reduces electricity usage and
provides superior cooling, is between 60°F (15°C) and 90°F (32°C).
It is recommended that you do not install the refrigerator near
a
heat source, such as an oven or radiator.
WARNING
Excessive Weight Hazard
Use two or more people to move and install
refrigerator.
Failure to do so can result in back or other injury.
When Moving Your Refrigerator:
Your refrigerator is heavy. When moving the refrigerator for
cleaning or service, be sure to cover the floor with
cardboard or hardboard to avoid floor damage. Always pull
the refrigerator straight out when moving it. Do not wiggle or
“walk” the refrigerator when trying to move it, as floor
damage could occur.
Important information to know about glass shelves
and covers:
Do not clean glass shelves or covers with warm water when
they are cold. Shelves and covers may break if exposed to
sudden temperature changes or impact, such as bumping.
Tempered glass is designed to shatter into many small,
pebble-size pieces. This is normal. Glass shelves and covers
are heavy. Use both hands when removing them to avoid
dropping.
WARNING
Explosion Hazard
Keep flammable materials and vapors, such as
gasoline, away from refrigerator.
Failure to do so can result in death, explosion, or fire.
2" (5.08 cm)
¹⁄₂
" (1.25 cm)
Product Specifications
| Brand: | Whirlpool |
| Category: | Refrigerator |
| Model: | WRF560SEHB |
Do you need help?
If you need help with Whirlpool WRF560SEHB, ask a question below and other users will answer you
Refrigerator Whirlpool User Manuals
26 October 2024
26 October 2024
25 October 2024
25 October 2024
25 October 2024
24 October 2024
15 October 2024
15 October 2024
15 October 2024
15 October 2024
Refrigerator User Manuals
- Refrigerator Candy
- Refrigerator Electrolux
- Refrigerator Samsung
- Refrigerator ATAG
- Refrigerator LG
- Refrigerator Bosch
- Refrigerator AEG
- Refrigerator IKEA
- Refrigerator Panasonic
- Refrigerator AEG Electrolux
- Refrigerator Bauknecht
- Refrigerator BEKO
- Refrigerator Etna
- Refrigerator Teka
- Refrigerator Severin
- Refrigerator Café
- Refrigerator Balay
- Refrigerator Miele
- Refrigerator Siemens
- Refrigerator Koldfront
- Refrigerator Arcelik
- Refrigerator Danby
- Refrigerator Bartscher
- Refrigerator Bertazzoni
- Refrigerator Smeg
- Refrigerator Hisense
- Refrigerator Hoover
- Refrigerator TCL
- Refrigerator Russell Hobbs
- Refrigerator Royal Catering
- Refrigerator Hotpoint
- Refrigerator Nabo
- Refrigerator Amica
- Refrigerator Ignis
- Refrigerator Inventum
- Refrigerator Artusi
- Refrigerator Cecotec
- Refrigerator Neff
- Refrigerator Bomann
- Refrigerator Edgestar
- Refrigerator Kogan
- Refrigerator Caple
- Refrigerator PKM
- Refrigerator Marvel
- Refrigerator G3 Ferrari
- Refrigerator Midea
- Refrigerator Sauber
- Refrigerator Liebherr
- Refrigerator Orbegozo
- Refrigerator Kuppersbusch
- Refrigerator Gorenje
- Refrigerator Summit
- Refrigerator Accucold
- Refrigerator Gram
- Refrigerator Haier
- Refrigerator Monogram
- Refrigerator Vox
- Refrigerator Westinghouse
- Refrigerator Orava
- Refrigerator Schneider
- Refrigerator Kluge
- Refrigerator Juno-electrolux
- Refrigerator DCG
- Refrigerator Coyote
- Refrigerator Grundig
- Refrigerator Stirling
- Refrigerator Privileg
- Refrigerator MPM
- Refrigerator Cosmo
- Refrigerator Khind
- Refrigerator KitchenAid
- Refrigerator Exquisit
- Refrigerator Euro Appliances
- Refrigerator Frigidaire
- Refrigerator Maytag
- Refrigerator Whynter
- Refrigerator GE
- Refrigerator Concept
- Refrigerator Guzzanti
- Refrigerator XO
- Refrigerator Omega
- Refrigerator Hitachi
- Refrigerator Fisher Paykel
- Refrigerator Hyundai
- Refrigerator Chiq
- Refrigerator Vintec
- Refrigerator Nevir
- Refrigerator Eqtemp
- Refrigerator Infiniton
- Refrigerator Indesit
- Refrigerator Daikin
- Refrigerator Jocel
- Refrigerator Blaupunkt
- Refrigerator Scandomestic
- Refrigerator Cylinda
- Refrigerator Respekta
- Refrigerator AYA
- Refrigerator Costway
- Refrigerator Dometic
- Refrigerator Blaze
- Refrigerator Sharp
- Refrigerator Husky
- Refrigerator Fridgemaster
- Refrigerator Fisher And Paykel
- Refrigerator Elba
- Refrigerator Worx
- Refrigerator Philco
- Refrigerator Jenn-Air
- Refrigerator Wisberg
- Refrigerator ECG
- Refrigerator HomeCraft
- Refrigerator Igloo
- Refrigerator Element
- Refrigerator Avanti
- Refrigerator Acros
- Refrigerator Kucht
- Refrigerator Glem Gas
- Refrigerator True
- Refrigerator Perlick
- Refrigerator Sub-Zero
- Refrigerator Koolatron
- Refrigerator Coca-Cola
- Refrigerator Kenmore
- Refrigerator Meireles
- Refrigerator Edesa
- Refrigerator IFB
- Refrigerator Profilo
- Refrigerator Milectric
- Refrigerator Tisira
- Refrigerator LERAN
- Refrigerator Zerowatt
- Refrigerator Baumatic
- Refrigerator Iberna
- Refrigerator Wolkenstein
- Refrigerator Hoover-Grepa
- Refrigerator Primo
- Refrigerator Svan
- Refrigerator Trisa
- Refrigerator Corberó
- Refrigerator Atosa
- Refrigerator Scancool
- Refrigerator FrigeluX
- Refrigerator Mora
- Refrigerator DAYA
- Refrigerator Thomson
- Refrigerator Salora
- Refrigerator Insignia
- Refrigerator Consul
- Refrigerator Aconatic
- Refrigerator Kuhla
- Refrigerator Hestan
- Refrigerator NewAir
- Refrigerator Yolco
- Refrigerator Sangiorgio
- Refrigerator Fhiaba
- Refrigerator Freggia
- Refrigerator Pelgrim
- Refrigerator Continental Edison
- Refrigerator Icecool
- Refrigerator Schaub Lorenz
- Refrigerator Premium Levella
- Refrigerator Linarie
- Refrigerator United
- Refrigerator JennAir
- Refrigerator Kalamazoo
- Refrigerator Brandy Best
- Refrigerator Snaigė
- Refrigerator Zanussi
- Refrigerator Lec Medical
- Refrigerator Signature
- Refrigerator Aspes
- Refrigerator Waltham
- Refrigerator Landmark
- Refrigerator Valberg
- Refrigerator Rex
- Refrigerator Pitsos
- Refrigerator Avallon
- Refrigerator Romo
- Refrigerator Benavent
- Refrigerator LeCavist
- Refrigerator Smart Brand
- Refrigerator Castor
Latest Refrigerator User Manuals
27 October 2024
27 October 2024
27 October 2024
27 October 2024
27 October 2024
27 October 2024
27 October 2024
27 October 2024
27 October 2024
27 October 2024
