Yaesu FT-818 Manual
Read below đź“– the manual in Italian for Yaesu FT-818 (15 pages) in the Receiver category. This guide has been helpful for 26 people and has been rated 4.5 stars on average by 2 users
Page 1/15
HF/VHF/UHF
SSB/CW/AM/FM ULTRA-COMPACT TRANSCEIVER
FT-818
ND
Operating Manual
Contents
Introduction ...................................................... 1
Safety Precautions .......................................... 2
Accessories & Options ................................... 4
Supplied Accessories ...................................... 4
Available Options ............................................ 4
Installation ........................................................ 5
Connecting the Supplied YHA-63 Antenna ..... 5
Connecting the Microphone ............................ 6
Shoulder Strap Installation .............................. 6
Rubber Foot Installation .................................. 6
Alkaline Battery Installation and Use .............. 7
External Power Connections ........................... 8
SBR-32MH Ni-MH Battery Pack
Installation and Use ........................................ 9
Installation .................................................... 9
Charging ....................................................... 9
Front Panel Control & Switches ................... 10
Display Icons .............................................. 13
Side Panel Switch & Connectors ................. 14
Rear Panel Connectors ................................. 15
Operation ........................................................ 16
Turning the Transceiver On and O󰀨 .............. 16
Supply Voltage Display ................................. 16
Operating Band Selection ............................. 17
Mode Selection ............................................. 17
Adjusting the Audio Volume Level ................. 17
Menu Quick Start .......................................... 18
Adjusting the RF Gain and Squelch .............. 18
Setting the Operating Frequency .................. 19
Stacked VFO System .................................... 19
Operation on 5 MHz Band (U.S. Version Only)
... 20
Receiver Accessories ................................... 21
Clariîšżer (Receiver Incremental Tuning) ........ 21
IF SHIFT ....................................................... 22
AGC (Automatic Gain Control) ...................... 22
Noise Blanker ................................................ 23
IPO (Intercept Point Optimization) ................ 23
ATT (Front End Attenuator) ........................... 23
AM/FM DIAL.................................................. 24
Automatic Power-O󰀨 Feature ....................... 24
Transmitter Operation ................................... 25
SSB Transmission ......................................... 25
Basic Setup/Operation ............................... 25
VOX Operation ........................................... 26
CW Transmission .......................................... 27
Operation using Straight Key/
External Keying Device .............................. 27
Operation using Built-in Electronic Keyer ... 29
FM Transmission ........................................... 30
Basic Setup/Operation ............................... 30
Repeater Operation .................................... 30
DCS Operation ........................................... 32
ARTS
TM
(Auto Range Transpond System)
Operation .................................................... 33
CW Identiîšżer Setup .................................... 33
Digital Mode Operation (SSB-Based AFSK)
.... 34
RTTY (Radio TeleType) Operation ............. 34
PSK31 Operation ....................................... 35
“USER” Dened Digital Modes ................... 36
Packet (1200/9600 bps FM) Operation ......... 37
AM Transmission .......................................... 38
Split Frequency Operation ............................ 38
Time-Out Timer ............................................. 39
Weather Fax Monitoring ................................ 39
Memory Operation ......................................... 40
QMB Channel ............................................... 40
QMB Channel Storage ............................... 40
QMB Channel Recall .................................. 40
Memory Operation on “Regular”
Memory Channels ......................................... 41
Normal Memory Storage ............................ 41
Split-Frequency Memory Storage ............... 41
Memory Channel Recall ............................. 42
Masking Memory ........................................ 42
Memory Operation on “HOME” Channel
Memories ...................................................... 43
HOME Channel Storage ............................. 43
HOME Channel Recall ............................... 43
Labeling Memories ........................................ 44
Setting the Spectrum Scope Mode ............. 45
Activate the Spectrum Scope ..................... 45
Spectrum Scope Monitor Operation ............ 45
Smart Search™ Operation ............................ 46
Scanning Operation ...................................... 47
Scanning Operation ...................................... 47
Scan Skip Programming (Memory Mode Only)
...
48
Programmable Memory Scan (PMS) Operation
... 49
Dual Watch Operation ................................... 50
Operation on Alaska Emergency
Frequency: 5167.5 khz (U.S. Version Only)
... 51
Menu Operation ............................................. 52
Cloning ........................................................... 63
CAT System Programming ........................... 64
CAT Data Protocol ........................................ 65
Constructing and Sending CAT Commands
... 65
Opcode Command Chart ........................... 66
Installation of Optional Accessories ........... 68
Optional Filters YF-122S/YF-122C/YF-122CN
... 68
Power-on Microprocessor Reset Procedure
... 69
Appendix ........................................................ 69
BAND DATA FORMAT .................................. 69
Speciîšżcations ................................................ 70
1
Introduction
The FT-818 is a compact, innovative multiband, multimode portable transceiver for the
amateur radio MF/HF/VHF/UHF bands. Providing coverage of the 160-10 meter bands
plus the 6 m, 2 m, and 70 cm bands, the FT-818 includes operation on the SSB, CW, AM,
FM, and Digital modes, yielding the most comprehensive performance package available
for portable operation.
Designed for use with either an external DC power source or internal batteries. The
FT-818 provides 6 watts of power output from a 13.8-Volt external power supply. When
using the SBR-32MH Ni-MH battery pack or Alkaline Battery Holder, the FT-818 will auto-
matically reduce the output power (2.5 Watts or more).
The multi-function Liquid-Crystal Display includes Blue, Amber, and Violet backlighting,
which may be disabled for battery conservation. The display includes bar-graph indication
of power output, ALC voltage, SWR, and modulation level. Also include are a number of
operating status icons, as well as the function displays for the three operating function
keys (
, , and ).
Among the advanced features of the FT-818 are many incorporated only in large base-sta-
tion transceivers. These include Dual VFOs; Split-Frequency operation; IF Shift; Clariîšżer
(“R.I.T.”); IF Noise Blanker; AGC Fast/Slow/Auto/O󰀨 selection; RF Gain and Squelch con-
trol; IPO (Intercept Point Optimization) and a receiver front-end Attenuator; AM Aircraft
reception; AM and FM Broadcast reception; VOX; Built-in Electronic Keyer; Adjustable CW
Pitch; Automatic FM Repeater Shift (ARS); Built-in CTCSS Encoder/Decoders; ARTS™
(Auto-Range Transponder System); Smart Search™ Automatic Memory Loading System;
Spectrum Scope; 200 Memories plus Home Channels and Band-limiting Memories; Al-
pha-Numeric Labeling of Memories; Automatic Power-O󰀨 (APO) and Time-Out Timer (TOT)
functions; Computer Interface capability; and Cloning capability.
We urge you to read this manual in its entirety, so as to gain a full understanding of the
amazing capability of the exciting FT-818 Portable Transceiver.
Product Specifications
| Brand: | Yaesu |
| Category: | Receiver |
| Model: | FT-818 |
Do you need help?
