Page 1/12
4K/UHD HDMI Over 100M
HDBaseT TX/RX with Ethernet,
Control, and PoE
AT-UHD-EX-100CE-TX & AT-UHD-EX-100CE-RX
AT-UHD-EX-100CE-KIT
atlona.com
Toll free: 1-877-536-3976
Local: 1-408-962-0515
2
1. Introduction ................................................................................... 3
2. Package Contents ................................................................................... 3
3. Features ................................................................................... 3
4. Before You Start ................................................................................... 3
5. Category Cable ................................................................................... 4
6. Panel Descriptions
a. Front Panel ................................................................................... 5
b. Rear Panel ................................................................................... 6
7. Captive Screw Connectors ................................................................................... 7
8. Connection Diagram ................................................................................... 8-9
9. Specifications ................................................................................... 10
10. Safety Information ................................................................................... 11
atlona.com
Toll free: 1-877-536-3976
Local: 1-408-962-0515
Table of Contents
3
atlona.com
Toll free: 1-877-536-3976
Local: 1-408-962-0515
Introduction
Pass through support of 4K (UHD), , IR, RS-232, bi-directional Ethernet, and lossy/lossless 2560x2048
audio signals up to 328ft (100m). The 100CE extenders provide an affordable, high quality, solution
for your audio and video needs.
Package Contents
Kit
TX
RX
Features
• 1 x AT-UHD-EX-100CE-TX
• 1 x AT-UHD-EX-100CE-RX
• 1 x 48V DC power supply
• 5 x Female captive screw connector (2 pin (x1): power, 3 pin (x2): RS-232, and 5 pin (x2): IR)
• 2 x Pair of wall/table mount ears
• 2 x Pair of screws for wall/mount ears
• 1 x IR emitter (AT-IR-CS-TX)
• 1 x User manual
• 1 x AT-UHD-EX-100CE-RX
• 1 x 48V DC power supply
• 2 x Female captive screw connector (3 pin: RS-232 and 5 pin: IR)
• 1 x Pair of wall/table mount ears
• 1 x Pair of screws for wall/mount ears
• 1 x IR emitter (AT-IR-CS-TX)
• 1 x User manual
• 1 x AT-UHD-EX-100CE-RX
• 2 x Female captive screw connector (3 pin: RS-232 and 5 pin: IR)
• 1 x Pair of wall/table mount ears
• 1 x Pair of screws for wall/mount ears
• 1 x IR emitter (AT-IR-CS-TX)
• 1 x User manual
• Extends IR, RS-232, Ethernet, and audio/visual content up to 328ft over a single category cable
• Supports resolutions up to 4K (UHD) 60Hz @ chroma sub-sampling 4:2:0 8-bit
• IR ports for use with IR remote controls and 3rd party IR controllers
• Bi-directional Ethernet pass through
• Provides PoE (Power over Ethernet)
• Multichannel audio pass through up to Dolby TrueHD, DTS-HD Master Audio, and Dolby Atmos
• Full 3D pass through
• HDCP 2.2 compliant
• Field updatable firmware
Before You Start
• When installing the extenders DO NOT:
Cover the vents
Install into a sealed wall
Install into an area without adequate air ventilation
