BASSBOSS AT212-MK3 Manual
Read below š the manual in Italian for BASSBOSS AT212-MK3 (14 pages) in the Speaker category. This guide has been helpful for 14 people and has been rated 4.5 stars on average by 2 users
Page 1/14
User ManUal
Dual 12ā 2-Way
Powered Loudspeaker
AT212-MK3
AT212-MK3 User Manual
2
Table of Contents
Overviewī 2
QuickīStartīGuideī 4
OutboardīProcessorīWarningī 5
SetupīProcedureī 5
OperationīandīControlsī 6
IndicatorīLEDsī 6
HowītoīUseītheīPresetsī 7
Pre-InstalledīOnboardīPresetsī 8
PowerīDistributionī 9
Troubleshootingī 9
Specificationsī 10
Warrantyī 11
SafetyīInformationī 12
ImportantīNotesī 13
FCCīComplianceīNoticeī 13
Overview
The AT212-MK3 is a very high-output, self-powered, internally processed, bi-amplified, 2-way, broad-
range loudspeaker. The cabinet is lightweight, the setup is easy and the output is smooth with a natural,
musical character. The remarkable power and eīiciency of the AT212-MK3 make it ideal for providers
who want to deliver high sound pressure levels but prefer not to move heavy cabinets.
Intended for use with a subwoofer system to complete a 3-way active full-range system, the AT212-MK3
has a tall, slim design that allows the HF horn to stand above crowds when the cabinet is stacked on
subwoofers. The light weight of the cabinet makes stacking by one person possible. The AT212-MK3
cabinets weigh only 99 lbs.
The AT212-MK3 is a vented cabinet that features two high-eīiciency 12ā woofers. The woofers feature
3.5ā voice coils, Neodymium magnets, cast aluminum baskets and ultra-light cones. The compression
driver also features a Neodymium motor structure with a 3ā voice coil. It is mated to a 1.4ā throat, cast
aluminum horn. The horn is rotatable, providing 80 x 60 degree coverage for multiple applications
including ground stack and horizontal or vertical flying.
EsteīmanualīestĆ”īdisponibleīenīespaƱolīenīnuestroīsitioīwebīenībassboss.com/support
Dual 12ā 2-Way
Powered Loudspeaker
AT212-MK3
bassboss.com
3
The AT212-MK3 is the ultimate in plug and play, with universal voltage compatibility and no need for any
outboard gear, other than a sound source. The built-in processing features presets that allow it to run in
multiple configurations. Each preset oīers advantages that suit specific applications and preferences.
Power is supplied by an amplifier that can deliver output peaks of 163V, to provide amazing dynamic
resolution and impact. The fully integrated and comprehensive digital processing ensures smooth
response and reliable operation thanks to meticulous filter alignments and five-stage limiters that
protect the drivers from excessive excursion, thermal overload and clipping. The amplifier features a
large heat sink and 2 temperature-controlled fans to ensure consistent operation, even under the most
extreme conditions.
The cones are waterproofed to protect them from accidental exposure to moisture such as rain or spilled
beverages. Weather resistant, IP65 rated power connectors, an internally sealed input section and
waterproof-treated cones are provided to allow operation where rain might be encountered.
The cabinet is built from 18mm and 15mm Birch plywood. It features an 18mm baīle and 18mm top and
bottom, with 15mm sides, port walls and braces, all assembled with dado joinery. The cabinet includes
4 steel bar-handles, 4 internally braced steel M10 fly points and a 35mm (1-3/8ā) cast metal pole socket.
Although the AT212 cabinet is equipped with a 35mm steel pole socket, DO NOT use this speaker on a
tripod or extension pole. This socket is to be used with a special, short section of pole to prevent it from
moving once stacked on a subwoofer.
The MK3 features an all-new DSP. The comprehensive suite of processing includes multiple presets,
each including multiple protection systems and limiters to prevent driver overload in as many ways
as possible, including thermal, excursion and clipping. There are five levels of protection that actively
prevent overheating of the voice coil, minimize long-term thermal compression and limit excursion.
Because they operate in 5 diīerent modes, the limiters are sophisticated enough to have a largely
unnoticable eīect on the transient response and allow the subwoofer to deliver peak output safely.
Each preset has a specific high-pass filter frequency and alignment filters that ensure itās output is
always phase coherent with any BASSBOSS sub. No matter which preset you choose, your BASSBOSS
subs and tops will always play in harmony.
The full-range mode, Preset 1, provides response down to 50Hz (-3dB). Each successive preset filters
the lows out at higher frequencies. As low-frequency demand is reduced, higher sound levels can be
achieved, allowing the AT212-MK3 to be used above multiple subwoofers.
Not including Cardioid, there are up to 56 possible combinations when MK3 tops are used with MK3
subs, but donāt worry, all are compatible. You canāt choose a āwrongā preset, you simply choose the
combination you like best.
The new DSP features an Ethernet interface. This can be used to control the cabinets from a computer
or to load software or firmware updates. The ethernet connectivity, in conjunction with the new DSP
board, will allow signal to be sent via Milan AVB. (Firmware updates will provide access to this feature.)
Within the software, multiple cabinets can be grouped together, allowing them to respond to commands
simultaneously. This permits the levels of groups of loudspeakers to be adjusted together, and yet
independently from the levels of other groups of loudspeakers. In addition to individual and grouped
level controls, presets can be loaded and signal levels and temperatures can be monitored. Each cabinet
includes a two-port switch, so multiple cabinets can be chained on the same data cable.
The MK3 DSP features storage capacity of up to 100 presets, eight of which can be accessed at the touch
of a button with no need for a connected computer. The eight directly accessible presets are compatible
with all the presets in the MK3 Top Boxes and are also compatible with previous generation tops and
subs.
