Page 1/2
Café
™
30" Slide-In Front Control Dual-Fuel
Convection Range with Warming Drawer
CC2S900P4MW2 / CC2S900P3MD1 / CC2S900P2MS1
ALSO
AVAILABLE IN
CC2S900P2MS1
Stainless Steel with
Brushed Stainless
handles and knobs
CC2S900P4MW2
Matte White with
Brushed Bronze
handles and knobs
FEATURES
FEATURES & BENEFITS
Expansive six-burner cooktop helps you entertain with ease - Entertaining for
large groups is easy with the industry's first six burner, edge-to-edge cooktop
that can accommodate cookware of all sizes and a cast-iron integrated griddle
that provides enough room to perfectly flip crab cakes, arepas and other
crowd favorites
Enjoy total control in the kitchen and beyond - Control your oven with your
smart device or simply your voice using WiFi Connect
An attractive appearance at all times - Every detail of your kitchen is designed
to delight, thanks to a sleek backlit glass touch control panel that visually
disappears when not in use and wakes up when prompted
Share favorite creations with your favorite people - Create an unforgettable
dinner, using a 21K tri-ring burner to do everything from searing scallops to
simmering a lemon caper white wine sauce and a 15K power boil burner to boil
water quickly for al dente angel hair pasta
Treat yourself to the best of both worlds - Get the precision you need to pull
off a multi-course dinner party with Dual Fuel, which boasts a gas-powered
cooktop for precise heat control and electric True European Convection with
Precise Air in the oven for even baking results.
Never scrub, smooth-glide racks - Easily remove heavy dishes with a roller rack
that is specially designed to glide smoothly and stay in the oven during the
self-clean cycle, so you never have to handle cumbersome racks again
Create a look that matches your personal style - Select any combination of
premium finishes and hardware options to create a stunning look customized
to any owner’s taste
Prepare foods to perfect doneness - Get roasts and meats just right with a
temperature probe that lets you monitor progress without opening the oven door
ACCESSORIES
Grates
Included Center Grate
Grill
Optional; Integrated Cast Iron; JXCGRILL1
LP Conversion Kit
Included
Trim Kit
Optional; JXFILLR1DD
Griddle
Included; Integrated Cast Iron
WEIGHTS & DIMENSIONS
APPEARANCE
Cooktop Burner Grate Color
Matte Black
Installation
Power Cord Not Included
Oven Door Features
Big Clear View Oven Window
Handle
Professional Style; Customizable; Consumer Removable
Handle Design
Café
CAPACITY
Total Capacity (cubic feet)
5.7 cu ft
ADA
COMPLIANT
Configuration
Range with Warming Drawer
Cooking Technology
Convection
Cooking System
True European Precise Air Reversing
Oven Cleaning Type
Self-Clean with Steam Clean Option
Burner - Left Front
21,000 BTU Tri-ring Burner
Burner - Left Rear
5,000 BTU Precise Simmer
Burner - Right Front
15,000 BTU
Burner - Right Rear
12,000 BTU
Burner - Center
9,500 BTU Front
/
9,500 BTU Rear
Cooktop Burner Type
Sealed
Cooktop Surface
Deep Recessed; Porcelain-Enamel; Gray
Dishwasher Safe Knobs
Yes
Control Location
Front controls
Control Type
Backlit; Glass Touch
Valves (Degree of Turn)
270
Oven Control Features
Audible Preheat Signal; Automatic Oven Timer
(Time Bake); Auto Oven Shut-Off Auto Self Clean;
Certified Sabbath Mode; Chef Connect; Control
Lock Capability; Delay Bake Option (Time Bake);
Delay Clean Option; Digipad Numeric Entry;
Electronic Clock and Timer; Front Controls; In-Oven
Broiling; Temperature Probe; Self-Clean Cool Down
Time Display
Oven Cooking Modes
Baked Goods (No Preheat); Convection Bake;
Convection Roast; Frozen Pizza Multi Rack (No
Preheat); Frozen Pizza Single Rack (No Preheat);
Frozen Snacks Multi Rack (No Preheat); Frozen
Snacks Single Rack (No Preheat); Proof; Warming
Oven Features
8-Pass Broil Element
Cooktop Burner Grate Features
Heavy-Cast Edge-to-Edge Grates
Cooktop Burner Grate Material
Cast-Iron
Cleaning Time
Variable with Delay Clean Option
Self-Clean Oven Door Lock
Automatic
Oven Rack Features
2 Self-Clean Oven Racks;
1
Roller Rack;
6 Rack Positions
Fuel Type
240V Electric and Natural Gas
Ignition System
Electronic w/Auto Reignition
Leveling System
4 Leveling Legs
Style
Commercial
Oven Interior
1 Incandescent; Hidden Bake; Black
Connected Capabilities
Amazon Alexa; The Google Assistant; IFTTT; Nest;
Drop; Innit; DiGiorno
Cabinet Opening
30 in
Depth with Door Open
47-1/2 in
Approximate Shipping Weight
244 lb
Net Weight
224 lb
Height to Top of Rear Vent Trim
37-3/8 in
Overall Height
37-3/8 in
Height to Cooking Surface (in.)
36-1/4 +/- 1/4
Overall Width
29-7/8 in
Cabinet Width
30 in
Overall Depth
29-1/2 in
Depth Without Handle
26-7/8 in
Oven Interior Dimensions
(W x H x D) (in.)
24 x 19-7/8 x 20-5/8
Café
™
30" Slide-In Front Control Dual-Fuel
Convection Range with Warming Drawer
CC2S900P4MW2 / CC2S900P3MD1 / CC2S900P2MS1
DIMENSIONS
Electrical Requirements:
240v/208v; 60Hz, 30A
Installation information:
Before installing, consult
installation instructions
packed with product for
current dimensional data.
For all installations,
install
the required rear trim
to back of range with 4
1 1/8"
36 1/4"
+/- 1/4"
16"
max to
cabinets
30"
36" min
See note A
Side Wall
18"
minimum
to cabinet
above counter
screws provided.
26 7/8"
w/o handle
29 3/8"
above
counter
Recommended
Wall-Mounted
0"
minimum
to cabinets
below
cooktop
24"
2 1/4"
8"
36"
6"
right side
6"
left side
minimum
to side wall
w/handle
47 1/2"
29 7/8"
7 1/2"
2"
9"
7"
3"
30"
Note A: 36" Minimum to bare cabinet, see
installation instructions for heights less than 36"
ADDITIONAL ACCESSORIES
CXFCGHKPMBZ
Brushed Bronze
2 handles; 6 knobs
CXFCGHKPMSS
Brushed Stainless
2 handles; 6 knobs
CXFCGHKPMBT
Brushed Black
2 handles; 6 knobs
CXFCGHKPMCU
Brushed Copper
2 handles; 6 knobs
For answers to your Café™ product questions, visit our website at cafeappliances.ca.
© 2019 GE Appliances PC93084 8/19
WARRANTY
Parts warranty
Limited 1-year entire appliance
Labor warranty
Limited 1-year entire appliance
POWER / RATINGS
Amp Rating at 208V
30
Amp Rating at 240V
30
Bake/Broil Wattage - Main Oven
2850/4000W
Convection Wattage
2500W
Top Burner BTU Rating -
LP (000's BTU's)
(1) 18.0 Tri-Ring; (1) 15.0; (1) 12.0; (2) 9.5; (1) 5.0
Top Burner BTU Rating -
Nat. Gas (000's BTU's)
(1) 21.0 Tri-Ring; (1) 15.0; (1) 12.0; (2) 9.5; (1) 5.0;
Volts/Hertz/Amps
208/240V; 60Hz; 30A
Power Connection
Power Cord - Not Included
Product Specifications
| Brand: | Café |
| Category: | Oven |
| Model: | CC2S900P4MW2 |
