Elation KL PANEL XL IP Manual
Read below 📖 the manual in Italian for Elation KL PANEL XL IP (42 pages) in the Relief category. This guide has been helpful for 24 people and has been rated 4.5 stars on average by 2 users
Page 1/42
PANEL XL IP
User Manual
2
Date
Document
Version
Software
Version
DMX Channel Mode Notes
08/23/22 1.0 1.07 1/4/7/6/12/24/48/96/14/23/58/04/12 Initial Release
12/13/22 1.1 N/C No Change
Updated Dimensional Drawings,
Specications
08/01/23 1.2 N/C No Change
Updated IP65 statement and
thermal specication
©2023 ELATION PROFESSIONAL all rights reserved. Information, speci󰤱cations, diagrams, images, and
instructions herein are subject to change without notice. ELATION PROFESSIONAL logo and identifying
product names and numbers herein are trademarks of ELATION PROFESSIONAL. Copyright protection
claimed includes all forms and matters of copyrightable materials and information now allowed by
statutory or judicial law or hereinafter granted. Product names used in this document may be trademarks
or registered trademarks of their respective companies and are hereby acknowledged. All non-ELATION
brands and product names are trademarks or registered trademarks of their respective companies.
ELATION PROFESSIONAL and all a󰤳liated companies hereby disclaim any and all liabilities for property,
equipment, building, and electrical damages, injuries to any persons, and direct or indirect economic
loss associated with the use or reliance of any information contained within this document, and/or as a
result of the improper, unsafe, insu󰤳cient and negligent assembly, installation, rigging, and operation
of this product.
Elation Professional USA | 6122 S. Eastern Ave. | Los Angeles, CA. 90040
323-582-3322 | 323-832-9142 fax | www.elationlighting.com | info@elationlighting.com
Elation Professional B.V. | Junostraat 2 | 6468 EW Kerkrade, The Netherlands
+31 45 546 85 66 | +31 45 546 85 96 fax | www.elationlighting.eu | info@elationlighting.eu
Elation Professional Mexico | AV Santa Ana 30 | Parque Industrial Lerma, Lerma, Mexico 52000
+52 (728) 282-7070
DOCUMENT VERSION
Due to additional product features and/or enhancements, an updated version of this
document may be available online. Please scan the QR Code with your mobile device or
visit www.elationlighting.com for the latest revision/update of this manual, before
installation and/or programming.
3
CONTENTS
General Information 4
Limited Warranty 5
Safety Guidelines 6
Maintenance Guidelines 8
IP65 Rated 9
Fixture Overview 10
Fan Modes and Low Noise Operation
Torque Screw Settings
11
12
Installation Instructions 13
Clamp Installation 14
Junior Pin Installation 15
Stand Mount Installation 16
Barn Door Installation 17
Intensifier Installation 18
Power Cables 19
Battery Connection 21
System Menu 22
Manual Mode 26
DMX Traits: 27
Channel Functions & Values 27
FX Table 31
FX Adjust Table 33
Color Temperature 34
Virtual Swatch Book 35
Remote Device Management (RDM)
Error Codes
36
37
Refresh Rate 37
Dimmer Modes / Dimmer Curves 38
Pixel Zones 39
Specifications 40
Dimensional Drawings 41
Optional Accessories | FCC Statement 42
