Page 1/10
710W Corded Jigsaw
With Variable Speed Control
Original
Instruction
Manual
Read instructions before operating tools
Models manual is applicable to:
RAGE7-S 230V UK (075-0001)
RAGE7-S 110V UK (075-0002)
RAGE7-S 230V EU (075-0003)
RAGE7-S 120V US (075-0004)
RAGE7-S BLADES (075-0200)
PUBLISHED DATE: 01.12.12
®
® ®
2 3
www.evolutionpowertools.com www.evolutionpowertools.com
TABLE OF CONTENTS
Important Information ...................................... 03
Evolution Limited Guarantee ........................... 03
General Safety Rules ...................................... 03
Additional Specic Safety Rules ...................... 05
Labels & Symbols ............................................ 07
Specication .................................................... 07
Jigsaw Overview.............................................. 08
Operating Instructions ..................................... 09
Cutting Advice.................................................. 15
Maintenance .................................................... 16
Environmental Protection ................................ 16
EC - Declaration of Conformity ........................ 17
A parts diagram is available online at:
www.evolutionpowertools.com
This instruction manual was
originally written in English.
IMPORTANT
Please read these operating and safety
instructions carefully and completely.
For your own safety, if you are uncertain about
any aspect of using this equipment please access
the relevant Technical Helpline, the number of
which can be found on the Evolution Power Tools
website. We operate several Helplines throughout
our worldwide organization, but technical help is
also available from your supplier.
WEBSITE
www.evolutionpowertools.com/register
Congratulations on your purchase of an
Evolution Power Tools Machine. Please
complete your product registration ‘online’
as explained in the A5 online guarantee
registration leaet included with this machine.
You can also scan the QR code found on the
A5 leaet with a Smart Phone. This will enable
you to validate your machine’s guarantee
period via Evolution’s website by entering
your details and thus ensure prompt service
if ever needed. We sincerely thank you for
selecting a product from Evolution.
EVOLUTION LIMITED GUARANTEE
Evolution Power Tools reserves the right to make
improvements and modications to the product
design without prior notice.
Please refer to the guarantee registration leaet
and/or the packaging for details of the terms,
conditions and period of the guarantee.
Evolution Power Tools will, within the guarantee
period, and from the original date of purchase,
repair or replace any goods found to be defective in
materials or workmanship. This guarantee is void if
the tool being returned has been used beyond the
recommendations in the Instruction Manual or if the
machine has been damaged by accident, neglect,
or improper service. This guarantee does not apply
to machines and / or components which have
been altered, changed, or modied in any way, or
subjected to use beyond recommended capacities
and specications. Electrical components are
subject to respective manufacturers’ warranties.
All goods returned defective shall be returned
prepaid freight to Evolution Power Tools. Evolution
Power Tools reserves the right to optionally repair or
replace it with the same or equivalent item. There
is no warranty – written or verbal – for consumable
accessories such as (following list not exhaustive)
blades, cutters, drills, chisels or paddles etc. In no
event shall Evolution Power Tools be liable for loss
or damage resulting directly or indirectly from the
use of our merchandise or from any other cause.
Evolution Power Tools is not liable for any costs
incurred on such goods or consequential damages.
No ofcer, employee or agent of Evolution Power
Tools is authorized to make oral representations of
tness or to waive any of the foregoing terms of sale
and none shall be binding on Evolution Power Tools.
Questions relating to this limited guarantee
should be directed to the company’s head
ofce, or call the appropriate Helpline number.
POWER TOOL GENERAL
SAFETY INSTRUCTIONS
(These General Power Tool Safety Instructions
are as specied in BS EN 60745-1:2009 & EN
61029-1:2009)
WARNING:
Read all safety warnings and instructions.
Failure to follow the warnings and instructions may
result in electric shock, re and/ or serious injury.
Save all warnings and
instructions for future reference.
The term “power tool” in the warnings refers to
your mains-operated (corded) power tool or
battery-operated (cordless) power tool.
1) General Power Tool Safety Warnings
[Work area safety]
a) Keep work area clean and well lit.
Cluttered or dark areas invite accidents.
b) Do not operate power tools in explosive
atmospheres, such as in the presence of
ammable liquids, gasses or dust. Power tools
create sparks which may ignite the dust or fumes.
c) Keep children & bystanders away while
operating power tool. Distractions can cause
you to lose control.
® ®
4 5
www.evolutionpowertools.com www.evolutionpowertools.com
2) General Power Tool Safety Warnings
[Electrical Safety]
a) Power tool plugs must match the outlet.
Never modify the plug in any way. Do not use
any adapter plugs with earthed (grounded)
power tools. Unmodied plugs and matching
outlets will reduce the risk of electric shock.
b) Avoid body contact with earthed or
grounded surfaces, such as pipes, radiators,
ranges and refrigerators. There is an increased
risk of electric shock if your body is earthed or
grounded.
c) Do not expose power tools to rain or wet
conditions. Water entering a power tool will
increase the risk of electric shock.
d) Do not abuse the cord. Never use the cord
for carrying, pulling or unplugging the power
tool. Keep cord away from heat, oil, sharp
edges or moving parts. Damaged or entangled
cords increase the risk of electric shock.
e) When operating a power tool outdoors, use
an extension cord suitable for outdoor use.
Use of a cord suitable for outdoor use reduces
the risk of electric shock.
f) If operating a power tool in a damp location
is unavoidable, use a residual current device
(RCD) protected supply. Use of an RCD reduces
the risk of electric shock.
3) General Power Tool Safety Warnings
[Personal Safety].
a) Stay alert, watch what you are doing and
use common sense when operating a power
tool. Do not use a power tool while you are
tired or under the inuence of drugs, alcohol
or medication. A moment of inattention while
operating power tools may result in serious
personal injury.
b) Use personal protective equipment. Always
wear eye protection. Protective equipment such
as dust masks, non-skid safety shoes, hard hat or
hearing protection used for appropriate conditions
will reduce personal injuries.
c) Prevent unintentional starting. Ensure the
switch is in the off-position before connecting
to power source and or battery pack, picking
up or carrying the tool. Carrying power tools with
your nger on the switch or energising the power
tools that have the switch on invites accidents.
d) Remove any adjusting key or wrench before
turning the power tool on. A wrench or key left
attached to a rotating part of a power tool may
result in personal injury.
e) Do not overreach. Keep proper footing and
balance at all times. This enables better control
of the power tool in unexpected situations.
f) Dress properly. Do not wear loose clothing or
jewellery. Keep your hair, clothing and gloves
away from moving parts. Loose clothes, jewellery
or long hair can be caught in moving parts.
g) If devices are provided for the connection of
dust extraction and collection facilities, ensure
that these are connected and properly used.
Use of dust collection can reduce dust-related
hazards.
4) General Power Tool Safety Warnings
[Power tool use and care].
a) Do not force the power tool. Use the correct
power tool for your application. The correct
power tool will do the job better and safer at a rate
for which it was designed.
b) Do not use the power tool if the switch does
not turn it on or off. Any power tool that cannot
be controlled with the switch is dangerous and
must be repaired.
c) Disconnect the power tool from the power
source and/or battery pack from the power
tool before making any adjustments, changing
accessories, or storing power tools. Such
preventative safety measures reduce the risk of
starting the power tool accidentally.
d) Store idle power tools out of the reach of
children and do not allow persons unfamiliar
with the power tool or these Instructions
to operate the power tool. Power tools are
dangerous in the hands of untrained users.
e) Maintain power tools. Check for
misalignment or binding of moving parts,
breakage of moving parts and any other
condition that may affect the power tools
operation. If damaged, have the power tool
repaired before use. Many accidents are caused
by poorly maintained power tools.
f) Keep cutting tools sharp and clean. Properly
maintained cutting tools with sharp cutting edges
are less likely to bind and are easier to control.
g) Use the power tool, accessories and tool
bits etc. in accordance with these instructions,
taking into account the working conditions
and the work to be performed. Use of the power
tool for operations different from those intended
could result in a hazardous situation.
5) General Power Tool Safety Warnings
[Service]
a) Have your power tool serviced by a
qualied repair person using only identical
replacement parts. This will ensure that the
safety of the power tool is maintained.
OUTDOOR USE
WARNING: For your protection if this tool is to be
used outdoors it should not be exposed to rain,
or used in damp locations. Do not place the tool
on damp surfaces. Use a clean, dry workbench
if available. For added protection use a residual
current device (R.C.D.) that will interrupt the
supply if the leakage current to earth exceeds
30mA for 30ms. Always check the operation of
the residual current device (R.C.D.) before using
the machine.
If an extension cable is required it must be a
suitable type for use outdoors and so labelled.
The manufacturers instructions should be
followed when using an extension cable.
HEALTH ADVICE
WARNING: When drilling, sanding, sawing or
grinding, dust particles will be produced. In some
instances, depending on the materials you are
working with, this dust can be particularly harmful
to you (e.g. lead from old gloss paint).You are
advised to consider the risks associated with the
materials you are working with and to reduce
the risk of exposure. Some wood and wood
type products, especially MDF (Medium Density
Fibreboard), can produce dust that may be
hazardous to your health. We recommend the use
of an approved face mask with replaceable lters
when using this machine, in addition to using the
dust extraction facility.
You should always:
• Work in a well-ventilated area.
• Work with approved safety equipment, such as
dust masks that are specially designed to lter
microscopic particles.
WARNING: If you suspect that paint on surfaces
in your home contains lead, seek professional
advice. Lead based paints should only be removed
by a professional and you should not attempt
to remove it yourself. Once the dust has been
deposited on surfaces, hand to mouth contact can
result in the ingestion of lead. Exposure to even
low levels of lead can cause irreversible brain and
nervous system damage. The young and unborn
children are particularly vulnerable.
ADDITIONAL SAFETY RULES FOR YOUR
EVOLUTION JIGSAW
1. Do not expose to rain or water.
2. Wear hearing protection when necessary.
Exposure to noise can cause hearing loss.
3. Cutting/scraping blades and accessories
can become very hot. Take care when changing
or handling any bits or accessories.
4. Hold the tool by the insulated gripping
surfaces, especially when performing an
operation where the blade may contact hidden
wiring. If the blade contacts a ‘live’ wire, exposed
metal parts of the power tool could become ‘live’
and give the operator an electric shock.
5. If possible, use clamps or a vice to hold
your work.
6. When cutting into walls, oors or similar
areas, make sure, as far as possible, that there
are no services (gas or water pipes, electric
cables etc) in the path of the blade. Striking
hidden services could cause injury to the user and
damage to the property.
7. Always disconnect the jigsaw from the
power supply before changing the blade.
Never use damaged or distorted blades.
8. Always allow the saw to come to a complete halt
before putting it down. A running tool may bounce
uncontrollably if the blade tip contacts any surface.
9. Always consider the work environment
and wear the appropriate personal protection
equipment. This could include dust masks, eye
protection, safety footwear etc.
Product Specifications
| Brand: | Evolution |
| Category: | Sawing machine |
| Model: | RAGE7-S |
Do you need help?
If you need help with Evolution RAGE7-S, ask a question below and other users will answer you
Sawing machine Evolution User Manuals
15 October 2024
15 October 2024
15 October 2024
15 October 2024
Sawing machine User Manuals
- Sawing machine Bosch
- Sawing machine DeWalt
- Sawing machine Royal Catering
- Sawing machine Gude
- Sawing machine Ryobi
- Sawing machine Hitachi
- Sawing machine Milwaukee
- Sawing machine Einhell
- Sawing machine Anova
- Sawing machine Metabo
- Sawing machine Vonroc
- Sawing machine Worx
- Sawing machine Stanley
- Sawing machine Black And Decker
- Sawing machine Powerplus
- Sawing machine Ozito
- Sawing machine Craftsman
- Sawing machine Maruyama
- Sawing machine Solo
- Sawing machine Triton
- Sawing machine Stalco
- Sawing machine Prime3
- Sawing machine MSW
- Sawing machine Yellow Garden Line
- Sawing machine Extralink
- Sawing machine CMI
- Sawing machine Goon
- Sawing machine Maxbear
- Sawing machine TAURUS Titanium
- Sawing machine Duro Pro
- Sawing machine Bestgreen
- Sawing machine MacAllister
- Sawing machine McKenzie
- Sawing machine Max Bahr
- Sawing machine Rona
- Sawing machine Bavaria By Einhell
Latest Sawing machine User Manuals
27 October 2024
27 October 2024
27 October 2024
27 October 2024
26 October 2024
26 October 2024
24 October 2024
22 October 2024
22 October 2024
21 October 2024
