Owner’s Manual
Havis Docking Station
For Getac RX10 Rugged Tablet
DS-GTC-510-SERIES_OMN_4-17
www.havis.com
1-800-524-9900
DS-GTC-510 Series
Havis, Inc.
75 Jacksonville Road
Warminster, PA 18974
www.havis.com 1-800-524-9900
DS-GTC-511
DS-GTC-511-3
DS-GTC-512
DS-GTC-512-3
DS-GTC-513
DS-GTC-513-3
DS-GTC-515
DS-GTC-515-3
DS-GTC-516
DS-GTC-516-3
Related Products
LPS-116
95W Power Supply
External in-vehicle power supply and cable for Getac
RX10 Rugged Tablet with cigarette lighter adaptor.
DS-DA-218
Desktop Stand for Tablet Docking Stations
Durable stand for mounting tablet Docking Stations
for use in the home or office.
DS-DA-501
Replacement Keys
Set of two (2) replacement keys for DS-GTC-500
Series Docking Stations.
DS-DA-808
Screen Blanking Solution with Tamperproof Cover
Powered by Blank-it, USB Dongle & Tamperproof Cover
for DS-GTC-500 Series Docking Stations.
Havis offers a wide variety of accessory products specically for use
with the DS-GTC-510 Series Docking Station. For more information or
to order, please visit www.havis.com.
www.havis.com • 1-800-524-9900
2 11
Before Beginning
(Original Instructions)
• NEVER STOW OR MOUNT THE DOCKING STATION DIRECTLY IN A VEHICLE
AIRBAG DEPLOYMENT ZONE.
• DO NOT USE COMPUTER WHILE DRIVING.
Havis is pleased to provide this Owner’s Manual to aid in the proper
installation and use of the DS-GTC-510 Series Docking Station for
Getac RX10 Rugged Tablets.
For questions regarding the set-up of your DS-GTC-510 Series Docking Station,
please contact Havis at 1-800-524-9900 or visit www.havis.com for additional
product support and information.
This Owner’s Manual applies to the following Part Numbers:
Operation - Undocking (continued)
• FOR DOCKING STATION MODELS EQUIPPED WITH A BUNDLED POWER SUPPLY
(DS-GTC-512, DS-GTC-512-3, DS-GTC-516, DS-GTC-516-3) REFER TO THE SUPPLIED LIND
POWER SUPPLY REFERENCE GUIDE.
• WHEN NOTEBOOK IS DOCKED, THE BATTERY WILL ONLY CHARGE BETWEEN
0°C to 50°C (32°F to 122°F).
PLEASE REFER TO GETAC RX10 OWNER’S MANUAL FOR MORE INFORMATION.
• READ ALL INSTRUCTIONS THOROUGHLY BEFORE BEGINNING INSTALLATION.
• DO NOT STORE, INSTALL, OR OPERATE THE DOCKING STATION WHERE WATER, MOISTURE,
STEAM, DUST, ETC. ARE PRESENT
• DO NOT DOCK OR UNDOCK YOUR COMPUTER UNLESS IT IS POWERED OFF. DOCKING OR
UNDOCKING WITH YOUR COMPUTER IN ON, STANDBY, HIBERNATION, OR SLEEP MODES
CAN CAUSE PERMANENT DAMAGE.
• FOR THE DS-GTC-511, DS-GTC-511-3, DS-GTC-512, DS-GTC-512-3, DS-GTC-515,
DS-GTC-515-3, DS-GTC-516, & DS-GTC-516-3 DOCKING STATIONS:
DO NOT CONNECT DIRECTLY TO VEHICLE VOLTAGE SOURCE: This product requires
a certied, automotive grade, Getac approved 95W power source rated for a
continuous, regulated 19VDC output (Havis Part Number LPS-116 or equivalent).
Failure to comply with this requirement will cause product damage that is NOT
repairable and is NOT covered under warranty.
• FOR THE DS-GTC-513 & DS-GTC-513-3 DOCKING STATIONS:
DO NOT CONNECT DIRECTLY TO VEHICLE VOLTAGE SOURCE: The Getac RX10 tablet
requires a certied, Getac approved power source rated for a continuous, regulated
19VDC output. Failure to comply with this requirement will cause product damage
that is NOT repairable and is NOT covered under warranty.
• DS-GTC-515. DS-GTC-515-3, DS-GTC-516, & DS-GTC-516-3 ARE EQUIPPED WITH A
+5V RS232 SERIAL PORT (PIN #9). BE CERTAIN TO VERIFY THAT YOUR PERIPHERAL DEVICE
IS COMPATIBLE WITH A POWERED RS232 PORT.
DS-GTC-511
DS-GTC-511-3
DS-GTC-512
DS-GTC-512-3
DS-GTC-513
DS-GTC-513-3
DS-GTC-515
DS-GTC-515-3
DS-GTC-516
DS-GTC-516-3
3) While Latch Mechansim is pushed down, carefully rock the top of the
computer forward and lift out of Docking Station
Table of Contents
10 3
Specications
Parts Included
Port Replication Capability
Antenna Identication
Installation
Cable Management
Operation - Docking
Operation - Undocking
4
5
6
6
7
8
9
10
• Do not place metal objects or containers of liquid on top of the Docking Station.
• If a malfunction occurs, immediately unplug the Power Supply and remove the laptop.
• Use only the specied Power Supply (Part # LPS-116) with this Docking Station.
• Do not connect cables into ports other than what they are specied for.
• Do not leave the Docking Station in a high temperature environment (greater than 85°C, 185°F)
for an extended period of time.
Precautions
1) If previously locked, unlock Docking Station using supplied key.
2) While holding computer with one hand, push down on Latch Mechanism
with thumb.
Operation - Undocking
Operation - Docking (continued)
3) For theft deterrence, secure computer by locking Docking Station with
supplied key (Hardware Kit Item 2).
