Page 1/12
Owner’s Manual
Havis Docking Station
For Panasonic Toughpad FZ-A1
DS-PAN-500-SERIES_OMN_8-13
www.havis.com
1-800-524-9900
DS-PAN-504
DS-PAN-505
DS-PAN-506
DS-PAN-500 Series
Havis, Inc.
75 Jacksonville Road, PO Box 2099
Warminster, PA 18974
47801 Anchor Court
Plymouth, MI 48170
www.havis.com 1-800-524-9900
www.havis.com • 1-800-524-9900
DS-PAN-504
DS-PAN-505
DS-PAN-506
Before Beginning
(Original Instructions)
2 11
Havis is pleased to provide this Owner’s Manual to aid in the proper
installation and use of the DS-PAN-500 Series Docking Station for
the Panasonic Toughpad FZ-A1.
For questions regarding the set-up of your DS-PAN-500 Series Docking Station,
please contact Havis at 1-800-524-9900 or visit www.havis.com for additional
product support and information.
This Owner’s Manual applies to the following Part Numbers:
• NEVER STOW OR MOUNT THE DOCKING STATION DIRECTLY IN A VEHICLE
AIRBAG DEPLOYMENT ZONE.
• DO NOT USE COMPUTER WHILE DRIVING.
• FOR DOCKING STATION MODELS EQUIPPED WITH A BUNDLED
POWER SUPPLY (DS-PAN-505), REFER TO THE SUPPLIED LIND
POWER SUPPLY REFERENCE GUIDE.
• WHEN TABLET IS DOCKED, THE BATTERY WILL ONLY CHARGE BETWEEN
0°C to 50°C (32°F to 120°F).
PLEASE REFER TO PANASONIC TOUGHPAD FZ-A1 OWNER’S MANUAL FOR
MORE INFORMATION.
Related Products
Havis offers a wide variety of accessory products specically for use
with the DS-PAN-500 Series Docking Station. For more information or
to order, please visit www.havis.com.
LPS-106
24W Power Supply
External in-vehicle power supply and cable for Panasonic
Toughpad FZ-A1 with cigarette lighter adaptor.
DS-DA-218
Desktop Stand for Tablet Docking Stations
Durable stand for mounting tablet Docking Stations
for use in the home or office.
DS-DA-503
Replacement Keys
Set of two (2) replacement keys for DS-PAN-500
Series Docking Stations.
• READ ALL INSTRUCTIONS THOROUGHLY BEFORE BEGINNING INSTALLATION.
• FOR THE DS-PAN-504, DS-PAN-505 DOCKING STATIONS:
DO NOT CONNECT DIRECTLY TO VEHICLE VOLTAGE SOURCE: This product
requires a certied, automotive grade, Panasonic approved 24W power
source rated for a continuous, regulated 12VDC output (Havis Part Number
LPS-106 or equivalent). Failure to comply with this requirement will cause
product damage that is NOT repairable and is NOT covered under warranty.
• FOR THE DS-PAN-506 DOCKING STATION:
DO NOT CONNECT DIRECTLY TO VEHICLE VOLTAGE SOURCE: The Panasonic
FZ-A1 tablet requires a certied, Panasonic approved power source rated
for a continuous, regulated 12VDC output. Panasonic recommends using
the power adapter included with the tablet; failure to comply with this
requirement will cause product damage that is NOT repairable and is NOT
covered under warranty.
www.havis.com • 1-800-524-9900
Table of Contents
10 3
Specications
Port Replication Capability
Parts Included
Installation
Cable Management
Operation - Docking
Operation - Undocking
3
4
4
6
8
9
10
Specications
Power Supply Input 12.0 V DC-In
Dimensions 10.8” ( 27.5 cm) H x 6.9” ( 17.6 cm ) W x 3.1” ( 8.0 cm ) D
Weight 1.6 lbs ( 0.68 kg )
Operating Environment -10° C to 50° C ( 14° F to 122°F )
Storage Environment -40° C to 85° C ( -40° F to 185° F )
• Do not place metal objects or containers of liquid on top of the Docking Station
• If a malfunction occurs, immediately unplug the Power Supply and remove the tablet
• Use only the specied Power Supply (Part # LPS-106) with this Docking Station
• Do not store the Docking Station where water, moisture, steam, dust, etc. are present
• Do not connect cables into ports other than what they are specied for
• Do not leave the Docking Station in a high temperature environment (greater than 85°C, 185°F)
for a long period of time
Precautions
EC DECLARATION OF CONFORMITY in accordance with EN 45014
Manufacturers Name: Havis, Inc.
Manufacturers Address: 47801 Anchor Court, Plymouth Twp, MI 48170 USA
Declares under our sole responsibility that the product:
Product name: Havis Docking Station For Panasonic Toughpad A1
Model: DS-PAN-50X, where ‘X’ may be any alphanumeric character and which describes product options.
May be followed by any alphanumeric characters which describe product options.
Product Options: This declaration covers all options of the above product which bear the CE Marking.
Is in conformity with the following standards or other normative documents:
EMC Directive 2004/108/EC: EN 55022:2010, Class B, Information technology equipment -
Radio disturbance characteristics - Limits and methods of measurement
EN 55024:2010, Information technology equipment - Immunity characteristics -
Limits and methods of measurement
Directive 2011/65/EU Restriction of the use of certain hazardous substances (RoHS)
BS EN 50498:2010: Section 7, after market electronic equipment in vehicles.
Supplementary Information:
The product herewith complies with the requirements of the EMC Directive 2004/108/EC. This product requires the
use of the provided e-Marked automotive power supply when used within vehicles.
Plymouth twp, MI, USA August 1, 2012 Bruce Jonik, Director of Engineering , Havis, Inc.
FCC 47CFR, Part 15 compliance: This is an FCC Class B device. Any changes or modications
to the model DS-PAN-50X not expressly approved by Havis, Inc. could void
the user's authority to operate this equipment.
3) Pivot tablet so the top aligns with the Locator Pin at the top of the
Docking Station. Lower the Latch Handle to secure tablet in place.
4) For theft deterrence, secure tablet by locking Docking Station with
supplied key (Hardware Kit Item 2).
Operation - Docking (continued)
Operation - Undocking
1) If previously locked, unlock Docking Station using supplied key.
2) While holding tablet with one hand, lift the Latch Handle on the top
of Docking Station.
3) Once unlatched grab both sides of tablet, rock the top forward and carefully
lift out of Docking Station, top end rst.
Latch Tab will
engage in front of
Toughpad FZ-A1
