Page 1/12
Owner’s Manual
Havis Docking Station
For Panasonic Toughpad FZ-G1
DS-PAN-700-SERIES_OMN_1-14
www.havis.com
1-800-524-9900
DS-PAN-701
DS-PAN-701-2
DS-PAN-702
DS-PAN-702-2
DS-PAN-703
DS-PAN-700 Series
Havis, Inc.
75 Jacksonville Road, PO Box 2099
Warminster, PA 18974
47801 Anchor Court
Plymouth, MI 48170
www.havis.com 1-800-524-9900
Related Products
Havis offers a wide variety of accessory products specically for use
with the DS-PAN-700 Series Docking Station. For more information or
to order, please visit www.havis.com.
LPS-114
90W Power Supply
External in-vehicle power supply and cable for Panasonic
Toughpad FZ-G1 with cigarette lighter adaptor.
DS-DA-218
Desktop Stand for Tablet Docking Stations
Durable stand for mounting tablet Docking Stations
for use in the home or office.
DS-DA-501
Replacement Keys
Set of two (2) replacement keys for DS-PAN-700
Series Docking Stations.
DS-DA-102
Night Eyes II
In-vehicle night time viewing from six long lasting,
soft true, red LED lights on a exible steel gooseneck.
www.havis.com • 1-800-524-9900
DS-PAN-701
DS-PAN-701-2
DS-PAN-702
DS-PAN-702-2
DS-PAN-703
Before Beginning
(Original Instructions)
2 11
Havis is pleased to provide this Owner’s Manual to aid in the proper
installation and use of the DS-PAN-700 Series Docking Station for
the Panasonic Toughpad FZ-G1.
For questions regarding the set-up of your DS-PAN-700 Series Docking Station,
please contact Havis at 1-800-524-9900 or visit www.havis.com for additional
product support and information.
This Owner’s Manual applies to the following Part Numbers:
• NEVER STOW OR MOUNT THE DOCKING STATION DIRECTLY IN A VEHICLE
AIRBAG DEPLOYMENT ZONE.
• DO NOT USE COMPUTER WHILE DRIVING.
• READ ALL INSTRUCTIONS THOROUGHLY BEFORE BEGINNING INSTALLATION.
• DO NOT DOCK OR UNDOCK YOUR COMPUTER UNLESS IT IS POWERED OFF. DOCKING OR
UNDOCKING WITH YOUR COMPUTER IN ON, STANDBY, HIBERNATION, OR SLEEP MODES
CAN CAUSE PERMANENT DAMAGE.
• FOR THE DS-PAN-701, DS-PAN-701-2, DS-PAN-702 & DS-PAN-702-2 DOCKING STATIONS:
DO NOT CONNECT DIRECTLY TO VEHICLE VOLTAGE SOURCE: This product requires
a certied, automotive grade, Panasonic approved 90W power source rated for a
continuous, regulated 15VDC output (Havis Part Number LPS-114 or equivalent).
Failure to comply with this requirement will cause product damage that is NOT
repairable and is NOT covered under warranty.
• FOR THE DS-PAN-703 DOCKING STATION:
DO NOT CONNECT DIRECTLY TO VEHICLE VOLTAGE SOURCE: The Panasonic FZ-G1 tablet
requires a certied, Panasonic approved power source rated for a continuous, regulated
16VDC output. Panasonic recommends using the power adapter included with the tablet;
failure to comply with this requirement will cause product damage that is NOT repairable
and is NOT covered under warranty.
• FOR DOCKING STATION MODELS EQUIPPED WITH A BUNDLED POWER SUPPLY
(DS-PAN-702, DS-PAN-702-2), REFER TO THE SUPPLIED LIND POWER SUPPLY
REFERENCE GUIDE.
• WHEN TABLET IS DOCKED, THE BATTERY WILL ONLY CHARGE BETWEEN
0°C to 50°C (32°F to 120°F).
PLEASE REFER TO PANASONIC TOUGHPAD FZ-G1 OWNER’S MANUAL FOR
MORE INFORMATION.
DS-DA-102 - Havis Night Eyes 2 (USB Powered LED Map Light)
(For further Installation Instructions, refer to the Instructions included with DS-DA-102)
1) Slide P-Clip over base of Map Light as shown, then line up the mounting
hole on P-Clip with Mounting Hole on Docking Station. Use provided
screw to secure light to the Docking Station.
2) Plug in USB from Map Light into an available USB Port on the Docking
Station and secure cable as needed with Zip Ties (Docking Station
Hardware Kit Item 1).
Installation of USB Map Lighting (DS-DA-102 - Optional)
DS-DA-102 provided
mounting screw
DS-DA-102
www.havis.com • 1-800-524-9900
Table of Contents
10 3
Specications
Port Replication Capability
Parts Included
Installation
Cable Management
Operation - Docking
Operation - Undocking
Installation of USB Map Light (DS-DA-102 - Optional)
3
4
4
6
7
8
10
11
• Do not place metal objects or containers of liquid on top of the Docking Station
• If a malfunction occurs, immediately unplug the Power Supply and remove the tablet
• Use only the specied Power Supply (Part # LPS-114) with this Docking Station
• Do not store the Docking Station where water, moisture, steam, dust, etc. are present
• Do not connect cables into ports other than what they are specied for
• Do not leave the Docking Station in a high temperature environment (greater than 85°C, 185°F)
for a long period of time
Precautions
Operation - Docking (continued)
Operation - Undocking
1) If previously locked, unlock Docking Station using supplied key.
2) While holding tablet with one hand, lift only the Latch Handle up
and rearward. Note that Latch Hook is spring loaded and will
follow Latch Handle.
3) Once unlatched grab both sides of tablet, rock the top forward and carefully
lift out of Docking Station, top end rst.
EC DECLARATION OF CONFORMITY in accordance with EN 50498
Manufacturers Name: Havis, Inc.
Manufacturers Address: 47801 Anchor Court, Plymouth Twp, MI 48170 USA
Declares under our sole responsibility that the product:
Product name: Havis Docking Station For Panasonic Toughpad FZ-G1 tablets
Model: DS-PAN-70X, where ‘X’ may be any alphanumeric character and which describes product options.
May be followed by any alphanumeric characters which describe product options.
Product Options: This declaration covers all options of the above product which bear the CE Marking.
Is in conformity with the following standards or other normative documents:
Automotive EMC Directive EN 50498:2010, Electromagnetic compatibility (EMC) -
2004/108/EC: Product family standard for aftermarket electronic equipment in vehicles
Directive 2011/65/EU Restriction of the use of certain hazardous substances (RoHS)
Supplementary Information:
The product herewith complies with the requirements of the Automotive EMC Directive 2004/108/EC, Annex I, 6.5, 6.6, 6.8,
and 6.9. This product requires the use of a recommended e-Marked automotive power supply when used within vehicles.
Plymouth twp, MI, USA September 20, 2013 Bruce Jonik, Director of Engineering , Havis, Inc.
FCC 47CFR, Part 15 compliance: This is an FCC Class B device. Any changes or modications
to the model DS-PAN-70X not expressly approved by Havis, Inc. could void
the user's authority to operate this equipment.
Specications
Power Supply Input 16.0 V DC-In
Dimensions 10.0” ( 25.5 cm) H x 11.4” ( 28.9 cm ) W x 4.4” ( 11.1 cm ) D
Weight 2.55 lbs ( 1.16 kg )
Operating Environment -10° C to 50° C ( 14° F to 122°F )
Storage Environment -40° C to 85° C ( -40° F to 185° F )
4) For theft deterrence, secure tablet by locking Docking Station with
supplied key (Hardware Kit Item 2).
