IPGARD SUHN-4S Manual
Read below 📖 the manual in Italian for IPGARD SUHN-4S (16 pages) in the Switch category. This guide has been helpful for 28 people and has been rated 4.5 stars on average by 2 users
Page 1/16
Document ID: USM-0S0-MM2 Revision: 1.11
Made in U.S.A. www.iPGARD.com 1-800-284-2131
USER MANUAL
Advanced 2/4-Port HDMI Secure KVM Switch
SUHN-2S 2-Port Secure HDMI KVM with Audio
SUHN-2S-P 2-Port Secure HDMI KVM with Audio and CAC Support
SUHN-2D 2-Port Secure Dual-Head HDMI KVM with Audio
SUHN-2D-P 2-Port Secure Dual-Head HDMI KVM with Audio and CAC Support
SUHN-4S 4-Port Secure HDMI KVM with Audio
SUHN-4S-P 4-Port Secure HDMI KVM with Audio and CAC Support
SUHN-4D 4-Port Secure Dual-Head HDMI KVM with Audio
SUHN-4D-P 4-Port Secure Dual-Head HDMI KVM with Audio and CAC Support
SUHN-4Q-P 4-Port Secure Quad-Head HDMI KVM with Audio and CAC Support
Release Date: July 3rd, 2018
TABLE OF CONTENTS
3
4
4
4
5
11
11
12
12
13
14
14
14
15
TECHNICAL SPECIFICATIONS___________________________________________________________
WHAT’S IN THE BOX?_________________________________________________________________
SECURITY FEATURES_________________________________________________________________
SUHN FRONT AND REAR______________________________________________________________
INSTALLATION_______________________________________________________________________
CAC INSTALLATION: COMMON ACCESS CARD, SMART CARD READER__________________________
CAC PORT CONFIGURATION____________________________________________________________
AUDITING: Dumping the Event Log via User Menu Options___________________________________
RESET: Restore Factory Default_________________________________________________________
LED’s BEHAVIOR_____________________________________________________________________
SYSTEM OPERATION__________________________________________________________________
TROUBLESHOOTING__________________________________________________________________
TECHNICAL SUPPORT_________________________________________________________________
LIMITED WARRANTY STATEMENT_______________________________________________________
Advanced 2/4-Port HDMI Secure KVM Switch 2
TECHNICAL SPECIFICATIONS
Advanced 2/4-Port HDMI Secure KVM Switch 3
VIDEO
Format HDMI 2.0
Host Interface
SUHN-2S/SUHN-2S-P (2) HDMI 19 pin (female)
SUHN-2D/SUHN-2D-P/
SUHN-4S/SUHN-4S-P
(4) HDMI 19 pin (female)
SUHN-4D/SUHN-4D-P (8) HDMI 19 pin (female)
SUHN-4Q-P (16) HDMI 19 pin (female)
User Console
Interface
SUHN-2S/SUHN-2S-P/
SUHN-4S/SUHN-4S-P
(1) HDMI 19-pin (female)
SUHN-2D/SUHN-2D-P/
SUHN-4D/SUHN-4D-P
(2) HDMI 19-pin (female)
SUHN-4Q-P (4) HDMI 19-pin (female)
Max Resolution 3840x2160 @ 60Hz
DDC 5 volts p-p (TTL)
Input Equalization Automatic
Input Cable Length Up to 20 ft.
Output Cable Length Up to 20 ft.
USB
Signal Type USB 1.1 and 1.0 Keyboard and Mouse only. USB 2.0 for CAC connection.
Type A to B
SUHN-2S/SUHN-2D (2)
SUHN-2S-P/SUHN-2D-P/SUHN-4S/SUHN-4D (4)
SUHN-4S-P/SUHN-4D-P/SUHN-4Q-P (8)
User Console Interface
(2) USB Type-A for keyboard and mouse connection only
(1) USB Type-A for CAC connection (P models only)
AUDIO
Input (2)/(4) Connector Stereo 3.5mm Female
Output (1) Connector Stereo 3.5mm Female
POWER
Power Requirements
12V DC, 2A (minimum) power adapter with center-pin positive polarity. Quad head
models require a 12V DC 3A (minimum) power adapter with center-pin
positive polarity.
ENVIRONMENT
Operating Temp 32° to 104° F (0° to 40° C)
Storage Temp -4° to 140° F (-20° to 60° C)
Humidity 0-80% RH, non-condensing
CERTIFICATIONS
Security Accreditation Common Criteria Validated To NIAP, Protection Prole PSS Ver. 3.0
OTHER
Emulation USB 1.1 and USB 2.0 Compatible
Control Front Panel Buttons
