Page 1/32
ENGLISH
INSTRUCTION MANUAL
Rechargeable
WiFi Thermal Imager
• OVER 10,000
PIXELS TO
TROUBLESHOOT
HOT AND COLD
SPOTS
• ADJUSTABLE
EMISSIVITY
FROM 0.01
TO 0.99
• TRANSFER PHOTOS
WIRELESSLY USING
INTEGRATED WIFI
HOTSPOT
• RECHARGEABLE
LITHIUM ION BATTERY
T
II
270
-4° – 752°F
-20° –
400°C
2m
ENERGY
PERFORMANCE
VERIFIED
RENDEMENT
ÉNERGÉTIQUE
VÉRIFIÉ
EP XXXXXXX
ENERGY
PERFORMANCE
VERIFIED
RENDEMENT
ÉNERGÉTIQUE
VÉRIFIÉ
EP XXXXXXX
EP 5016393
5001748
SCAN TO
DOWNLOAD
THE APP
FRANÇAIS p. 21
ESPAÑOL pg. 11
2
GENERAL SPECIFICATIONS
The Klein Tools TI270 is an easy-to-use, USB-rechargeable WiFi
Thermal Imager for viewing unseen hot and cold spots for instant
troubleshooting. It provides high and low temperature points,
crosshairs to pinpoint specific temperatures, and options for
temperature alarms. WiFi setting allows the imager to transfer and
share images for reporting.
• Environment: Indoor: DO NOT expose to moisture rain or snow.
• Operating Altitude: 6562 ft. (2000 m)
• Relative Humidity: <85% non-condensing
• Operating Temp: 32° to 113°F (0° to 45°C)
• Storage Temp: -4° to 140°F (-20° to 60°C )
• Sensor: VOx Microbolometer
• Sensor Resolution: 10800 pixels (120 × 90)
• Field of View (FOV): 50° ±3°
• Frame Rate: <9 Hz
• Sensitivity: ≤60 mK
• Temperature Range: -4° to 752°F (-20° to 400°C)
• Temperature Resolution: 0.1°F/0.1°C
• Temperature Accuracy: ±3°C (±5.4°F) or 3% (whichever greater)
NOTE: Not calibrated below -10°C (14°F)
• Temperature Display: High, Low, and Center point
• Temperature Settings: °F / °C
• Emissivity: 0.01 to 0.99 adjustable (0.95 default)
• Display Type: 3.5" (89 mm) TFT LCD
• Color Palettes: Ironbow, Rainbow, Grayscale
• Image Format: JPG
• Image Storage: Up to 10000 thermal images
• Image Transfer: USB, or WiFi using the Klein Tools App
• Dimensions: 4.48" × 3.10" × 1.06" (113.7 × 78.7 × 26.9 mm)
• Weight: 7.5 oz. (213 g)
• Power: Lithium polymer battery (USB rechargeable)
3.7V / 2000mAh (7.4 Wh)
• Required Charger Voltage / Current : 5V DC, 2A
• Charging Current / Time: 1A / 4 hours
• Auto Power Off: User-selectable for 5, 10, or 30 minutes
• Pollution degree: 2
• Drop Protection: 6.6' (2 m)
• Standards: Conforms to UL STD. 61010-1
Certi ed to CSA STD. C22.2 No. 61010-1
Specifications subject to change.
ENGLISH
5001748
3
WARNINGS
Read, understand, and follow these instructions to ensure safe
operation. Failure to observe these warnings can result in risk of
 re or electric shock. Keep these instructions for future reference.
• DO NOT use the product if it is damaged or modified. Damaged or
modified batteries may exhibit unpredictable behavior resulting in
fire, explosion, or injury.
• Risk of fire and burns. DO NOT open, crush, heat above specified
maximum temperature or incinerate. Prolonged exposure to direct
sunlight can result in elevated temperatures.
• If the battery’s internal temperature gets too high, the unit will
shut down until the internal temperature is lowered.
• DO NOT expose to moisture, rain, or snow.
• DO NOT subject to impacts or drops greater than 6.6 ft. (2 m).
Drops larger than this may not show signs of damage, but internal
components may have been compromised. It is advisable to
replace the unit if any such severe events occur.
• There are no user-serviceable parts inside. DO NOT open or
attempt to repair.
WARNING SYMBOLS ON TESTER
Warning or caution
Risk of Electrical Shock
Read instructions before using
OTHER SYMBOLS ON TESTER
Conformité Européenne: Conforms with European
Economic Area directives
UKCA: UK Conformity Assessment
This product has been independently tested by Intertek
and meets applicable published standards.
WEEE: Electronics disposal
USB rechargeable
USB-C Port Cover (bottom of unit)
CAUTION
• BURN HAZARD. Reflective materials may have a higher actual
temperature than the measured temperature. Set emissivity to
match the object being measured (see Emissivity section).
• Do not point the camera at the sun or any other strong energy source.
This can affect the accuracy of the camera or cause damage to the sensor.
