SAFETY INFORMATION
To clean the GEMINI 1X1, wipe with a clean, dry, non-abrasive cloth only.
Weight (including Yoke, not including accessories): 5.5kg [12 lb]
Dimensions (including Yoke, not including accessories): W = 40.7 cm [16.0 in], H = 47.0 cm [18.5 in], D = 11.8 cm [4.7 in]
Do not restrict air flow around the GEMINI 1X1. Keep the fixture’s air intakes and air exhaust space clear of obstruction.
Plug the GEMINI 1X1 into a mains electrical outlet using only a provided AC IEC Power Cable or one specified by Litepanels
®
. Protect the cable from pinching,
twisting, or crushing. Use a mains electrical outlet that is grounded and rated for 100-240VAC, 50/60Hz only.
Do not use, mount, transport, or store the GEMINI 1X1 near radiators, space heaters, ovens, stoves, heat registers, open flame, or any heat source, or in an
environment with an ambient temperature greater than 65°C [149° F].
The GEMINI 1X1 is suitable for operation only in an environment as follows: ambient air temperature between -20°C and 45°C [between -4°F and 113°F]; less than
85% relative humidity (RH), no condensation. Use in a dry environment; do not place on a wet surface or submerge the GEMINI 1X1 in liquid.
WARNING: Tampering with or disassembling the GEMINI 1X1 may result in electric shock and will void the manufacturer’s warranty.
WARNING: To reduce the risk of electric shock or fire, do not expose the GEMINI 1X1 to rain, moisture, or liquids.
Immediately consult with qualified Litepanels
®
service personnel if any of the following have occurred: The fixture has been dropped or impacted; the power cable
has been damaged; the fixture has been exposed to rain, moisture, or liquid; or the fixture does not operate normally.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause
harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
STUDIO FULL COLOR SOFT PANEL LED FIXTURE (945-1001)
www.litepanels.com
PRESET BUTTONS (6X)
PRESET TOGGLE BUTTON
CANCEL BUTTON
DISPLAY
3-PIN XLR DC POWER INPUT JACK
ACTIVE COMMS INDICATOR LIGHT
GREEN OFFSET / HUE / MENU KNOB
CCT / SATURATION KNOB
DIMMER / INTENSITY KNOB
TVMP STAND ADAPTER
TVMP KNOB
(A)
(B)
(C)
(D)
(E)
(F)
(G)
(H)
(I)
(J)
(K)
IEC AC INPUT
5-PIN XLR DMX / INPUTMASTER/REPLICA
5-PIN XLR DMX / MASTER/REPLICA OUTPUT
BLUETOOTH
(R)
/ WIRELESS DMX PORT
ANTENNA
RJ45 DMX / OUTPUTMASTER/REPLICA
RJ45 DMX / INPUTMASTER/REPLICA
USB PORT
1/4-20 FEMALE THREAD (8X)
AIR INTAKE
YOKE KNOB
(L)
(M)
(N)
(O)
(P)
(Q)
(R)
(S)
(T)
(U)
(V)
YOKE
POWER / STATUS INDICATOR LIGHT
ON / OFF SWITCH
POWER SUPPLY ADAPTER
AIR EXHAUST SPACE
DOVETAIL CHANNEL (4X)
ACCESSORY LATCH
YOKE LOCKING PIN (2X)
ACCESSORY RAIL (3X)
(W)
(X)
(Y)
(Z)
(AA)
(AB)
(AC)
(AD)
(AE)
SEE REVERSE
INCLUDED
GEMINI 1X1 Soft Panel LED Fixture
GEMINI 1X1 Yoke
A
ABAA
O
B
C
D
N
S
AD
AC
T
V
K
W
Y
X
F
G
E
I
H
AE
Z
M
P Q R
U
J L
