*The specifications and pictures are subject to change without prior notice.
*All trade names referenced are the registered trademarks of their respective owners.
Features:
» Industrial switch, 4x 10/100/1000Base-TX RJ45 and 1x SFP ports
» Unmanaged, easy installation, plug-and-play
» Compact and rugged metal housing, IP40
» Free fall, shock and vibration stability
» Power input: 12 to 52 V DC redundant power
» Extended operation temperature: -40–80°C
» Suitable for DIN-rail mounting
Compact size 5-Port 10/100/1000 Base-TX Ethernet Switch, suitable for industrial application. Featuring
four 10/100/1000Base-TX RJ45 and one SFP ports, IP40-rated rugged aluminum case and a wide-ranging
redundant power system (12–52 V DC). It is able to operate in any harsh environment with operating
temperature ranging from -40 to 80°C.
Art. No.: NS204
Industrial Gigabit Ethernet
Switch, 4-Port 1000 Mbps
+ 1-Port SFP
Specification:
Protocols/Standards
IEEE 802.3, IEEE 802.3i, IEEE 802.3u, IEEE 802.3x, IEEE 802.3ab,
IEEE 802.3z
Interface 4x 10/100/1000 Mbps RJ45 ports + 1x SFP slot
Bandwidth 14 Gbps
Packet Buffer Memory 1.2 Mbit
Packet Forwarding Rate 10.5 Mpps
MAC Address Table 2K
Flow Control Back pressure for half duplex, IEEE 802.3x pause frame for full duplex
LED Indicator Power: Red; Ethernet: Yellow; SPF: Green
Network Cables
10Base-T: Cat.3/4/5 UTP (≤100 m); 100Base-Tx: Cat.5 or later UTP (≤100 m)
1000BASE-TX: Cat.6 or later UTP (≤100 m)
Power Input 12–52 V DC redundant power
Power Consumption Max. 3 W
*The specifications and pictures are subject to change without prior notice.
*All trade names referenced are the registered trademarks of their respective owners.
Package Contents:
» 1 x Gigabit Ethernet Switch
» 1 x User Manual
Package Information:
» Packing Dimension: 165 x 135 x 54
mm
» Packing Weight: 0.46 kg
» Carton Dimension: 445 x 350 x 343 mm
» Carton Q‘ty: 36 pcs
» Carton Weight: 16.6 kg
Installation DIN rail
Enclosure IP40 aluminum housing
MTBF >300,000 hours
Operating Temperature -40–80°C
Storage Temperature -40–80°C
Storage Humidity 5–95% RH non-condensing
Dimension 11.8 x 8.6 x 3.35 cm
Weight 0.36 kg
