Page 1/2
*The specifications and pictures are subject to change without prior notice.
*All trade names referenced are the registered trademarks of their respective owners.
Ferrule Crimping Tool Kit
Made in China
www.2direct.de
How to Use
Technical Features
Self-adjustable ratchet wire crimping tool with 1200 pcs wire end ferrules
Ferrule crimping range from 0,25–6 mm² (AWG 23–10)
Included ferrules : 200 pcs x 22 AWG (White), 200 pcs x 20 AWG (Grey), 200 pcs x 18 AWG (Red), 250 pcs x 16 AWG (Black), 250
pcs x 14 AWG (Blue), 50 pcs x 12 AWG (Grey), 50 pcs x 10 AWG (Yellow)
Product dimension: 175x81x24,5 mm
Strip the wire to proper length and
insert the wire into ferrule terminal.
Squeeze the handles together to
open the tool.
Insert the ferrule into the die
profile.
Close the tool slightly until the
ratchet engages in the end.
Release the handles,
the ferrule terminal is
tightly crimped
with the wire.
Art. No.: WZ0068
1
2
3
4
5
22 AWG
0,5 mm²
WHITE
200 PCS
18 AWG
1,0 mm²
RED
200 PCS
16 AWG
1,5 mm²
BLACK
250 PCS
14 AWG
2,5 mm²
BLUE
250 PCS
12 AWG
4,0 mm²
GREY
50 PCS
10 AWG
6,0 mm²
YELLOW
50 PCS
20 AWG
0,75 mm²
GREY
200 PCS
0,25–6,0 mm
2
(AWG 23–10)
*The specifications and pictures are subject to change without prior notice.
*All trade names referenced are the registered trademarks of their respective owners.
Package Content
Packaging Information
Packing Dimension
220x115x65 mm
Packing Weight
0,669 kg
Carton Dimension
510x240x365 mm
Carton Q‘ty
20 pcs
Carton Weight
15 kg
Made in China
1x Ferrule Crimping Tool
200x 22 AWG (White)
200x 20 AWG (Grey)
200x 18 AWG (Red)
250x 16 AWG (Black)
250x 14 AWG (Blue)
50x 12 AWG (Grey)
50x 10 AWG (Yellow)
www.2direct.de
