User Guide
MADIface XT II
Channels Galore!
USB 3 / USB 2.0 Digital I/O System
24 Bit / 192 kHz Digital Audio
192 Channels Triple MADI Interface
AES/EBU I/O
2 + 4 Channels Analog I/O
196 x 198 Matrix Router
3 x MIDI embedded in MADI
1 x MIDI I/O
2
User's Guide MADIface XT II © RME
Safety Instructions and Proper use
Read the manual carefully and completely before using the device. Pay attention to the
following information on how to use and operate the MADIface XT II safely. Improper
use can lead to loss of warranty claims (see warranty statement on page 118).
Proper Use
The MADIface XT II is a digital interface for professional audio applications for use with CE ap-
proved class B computers.
To comply with the European CE standard, the MADIface XT II must be used
with CE approved Class B computers. All connecting cables must be shielded.
The computer and all cables connected to the MADIface XT II must be properly
grounded. Operation with non-certified computers and cables may cause inter-
ference to other devices as well as the MADIface XT II.
Do not open chassis
No user serviceable parts inside. Refer service to qualified service personnel.
To reduce the risk of fire or electric shock do not expose this device to rain or
moisture. Prevent moisture and water from entering the device. Never leave a
pot with liquid on top of the device. Do not use this product near water, i. e.
swimming pool, bathtub or wet basement. Danger of condensation inside –
don't turn on before the device has reached room temperature.
Installation
Surface may become hot during operation – ensure sufficient ventilation.
Avoid direct sun light and do not place it near other sources of heat, like radi-
ators or stoves. When mounting in a rack, leave some space between this
device and others for ventilation.
Unauthorized servicing/repair voids warranty. Only use accessories specified by the
manufacturer.
User's Guide MADIface XT II © RME
3
Important Safety Instructions .................................. 2
General
1 Introduction ............................................................... 8
2 Package Contents ..................................................... 8
3 System Requirements .............................................. 8
4 Brief Description and Characteristics .................... 8
5 First Usage – Quick Start
5.1 Connectors – Controls - Display ................................ 9
5.2 Quick Start ........................................................... 10
5.3 Menu and Navigation ........................................... 11
5.4 Overview Menu Structure .................................... 11
Driver Installation and Operation - Windows
6 Hardware, Driver and Firmware
6.1 Driver Installation ..................................................... 14
6.2 De-Installing the Drivers ...................................... 14
6.3 Firmware Update ................................................. 14
7 Configuring the MADIface XT
7.1 Settings Dialog – Main Tab ...................................... 15
7.2 Option WDM Devices .............................................. 18
8 Operation and Usage
8.1 Playback .................................................................. 20
8.2 DVD Playback (AC-3 / DTS) ................................ 20
8.3 Multi-client Operation ........................................... 21
8.4 Digital Recording.................................................. 21
8.5 Analog Recording ................................................ 22
8.6 Clock Modes – Synchronization .......................... 22
9 Operation under ASIO
9.1 General .................................................................... 23
9.2 Channel Count under ASIO ..................................... 24
9.3 Known Problems .................................................. 24
10 Using multiple MADIface XT .................................. 25
11 DIGICheck Windows ............................................... 25
12 Hotline – Troubleshooting ..................................... 26
Driver Installation and Operation - Mac OS X
13 Driver and Flash Update
13.1 Driver Installation ................................................. 28
13.2 De-installing the Drivers ....................................... 28
13.3 Firmware Update ................................................. 28
14 Configuring the MADIface XT
14.1 Settings Dialog ..................................................... 29
14.2 Clock Modes – Synchronization .......................... 32
15 Mac OS X FAQ
15.1 MIDI doesn't work ................................................ 33
15.2 Repairing Disk Permissions ................................. 33
15.3 Supported Sample Rates ..................................... 33
15.4 Channel Count under Core Audio ........................ 33
15.5 Various Information .............................................. 34
16 Using multiple MADIface XT .................................. 34
17 DIGICheck NG Mac ................................................. 35
18 Hotline – Troubleshooting ..................................... 36
Product Specifications
