SPL MasterBay Manual
Read below 📖 the manual in Italian for SPL MasterBay (24 pages) in the Router category. This guide has been helpful for 33 people and has been rated 4.5 stars on average by 2 users
Page 1/24
Manual
SPL MasterBay
Insert
On
1
2
4
3
7
6
5
8
New
Save
1
Save
2
Save
3
Recall
1
Recall
2
Recall
3
Processor
8
Processor
7
Processor
6
Processor
5
Processor
4
Processor
3
Processor
2
Processor
1
MasterBay
Automated Patchbay
Model 2487-R
2
Manual, Version 1.1, 2/2006
R & D: Wolfgang Neumann
The information in this document has been carefully verified and is assumed to be
correct. However Sound Performance Lab (SPL) reserves the right to modify the
product described in this manual at any time. Changes without notice. This docu-
ment is the property of SPL and may not be copied or reproduced in any manner, in
part or full without the authorization of SPL.
Limitations of Liability:
In no event will SPL be liable for any damages, including loss of data, lost profits,
cost of cover or other special, incidental, consequential or indirect damages arising
from the use of the unit, however caused and on any theory of liability. This limita-
tion will apply even if SPL or an authorized dealer has been adviced of the possibility
of such damage.
Sound Performance Lab
SPL electronics GmbH
P.O. Box 12 27, D- 41368 Niederkruechten, Germany
Phone +49 2163 983 40, Fax +49 2163 983 420
Email: info@spl.info, Internet: spl.info
© 2006 SPL electronics GmbH
All rights reserved. Technical specifications and appearance are subject to change
without notice.
MasterBay, Models 2487, 2268, 2488 Manual
3
Contents
MasterBay Remote Control, Model 2487 ......................................................... 4
MasterBay Dual-Channel Insert Box, Model 2488 ........................................... 5
MasterBay Eight-Channel Insert Box, Model 2268 .......................................... 6
Wiring Diagram .............................................................................................. 7
Control Surface, Operation ............................................................................ 8
Operation ...................................................................................................... 9
EDAC 38 pin connectors/pin configuration ..................................................... 10
DB 25 pin connectors/pin configuration ......................................................... 11
Measurements ............................................................................................... 11
Warranty ........................................................................................................ 12
Automated routing of processors in a mastering chain is becoming more and more
of an issue for mastering engineers. The SPL MasterBay system allows for instant
comparison of single processors or processor chains which can be determined and
stored in three different sequences.
The MasterBay is availalable as dual- or eight-channel system. Each of the fully
balanced, entirely passive insert boxes is controlled by the MasterBay Remote
Control which can be placed upon the desktop or built into a desk.
Dual-channel MasterBay:
Remote Control model 2487 and insert box model 2488
Eight-channel MasterBay:
Remote Control model 2487 and insert box model 2268
