144 MHZ BAND FM TRANSCEIVER
FT-2600M
OPERATING MANUAL
VERTEX STANDARD CO., LTD.
4-8-8 Nakameguro, Meguro-Ku, Tokyo 153-8644, Japan
VERTEX STANDARD
US Headquarters
17210 Edwards Rd., Cerritos, CA 90703, U.S.A.
International Division
8350 N.W. 52nd Terrace, Suite 201, Miami, FL 33166, U.S.A.
YAESU EUROPE B.V.
P.O. Box 75525, 1118 ZN Schiphol, The Netherlands
YAESU UK LTD.
Unit 12, Sun Valley Business Park, Winnall Close
Winchester, Hampshire, SO23 0LB, U.K.
VERTEX STANDARD HK LTD.
Unit 5, 20/F., Seaview Centre, 139-141 Hoi Bun Road,
Kwun Tong, Kowloon, Hong Kong
Contents
General Description ............................1
Specifications.......................................2
Accessories & Options.........................3
Front Panel Controls and Switches.....4
Microphone Switches ..........................6
Rear Panel Connectors........................7
Installation...........................................8
Preliminary Inspection ...................................... 8
Installation Tips ............................................... 8
Safety Information ........................................... 8
RF Field Exposure Information ......................... 9
Antenna Considerations .................................... 9
Mobile Installation ......................................... 11
Base Station Installation ................................. 13
Operation .......................................... 15
Basic Operation/Reception.............................. 15
Power ON/OFF .......................................... 15
Supply Voltage Display .............................. 15
Adjusting the Volume and Squelch............... 15
Lock Feature ............................................... 16
Keypad Beeper ........................................... 16
Display Brightness ...................................... 17
Tuning: The “Dial” (VFO) Mode ................. 17
Channel Step Selection ................................ 17
Direct Keypad Frequency Entry
(MH-36
B6J
Microphone) 18
Transmission ................................................. 19
DTMF Keypad............................................ 19
1750 Hz Tone Call ...................................... 19
Power Output Setting .................................. 20
PTT Locking............................................... 20
Transmitter Thermal Protection Sensor ......... 21
Repeater Operation ........................................ 22
Repeater Splits ............................................ 22
Tone Squelch Modes ...................................... 25
CTCSS
(Continuous Tone Coded Squelch System). 25
DCS (Digital Code Squelch) ........................ 25
CTCSS/DCS Selections using
Programmable Microphone Key... 27
CTCSS Tone Search Scanning ..................... 27
DCS Tone Search Scanning ......................... 28
DCS Code Inversion.................................... 28
CTCSS Bell Paging ..................................... 29
DTMF Autodialer Operation ........................... 30
Memory System Operation ............... 32
Memory Storage ............................................ 32
To Append an Alpha-Numeric
Label to a Memory: ............ 32
Recalling Memories ....................................... 33
Memory Recall from MH-36B6J Microphone .... 33
To Turn on the Alpha-Numeric
Memory Name Display:..... 33
Home Channel Memory ................................. 34
Memory Offset Tuning ................................... 34
Memory-Only Mode ...................................... 35
Deleting Memories ......................................... 35
Scanning ............................................ 36
Basic Scanner Operation ................................. 36
Scan-Resume Options .................................... 36
Memory Skip Scanning (MR Mode)................ 37
Temporary Memory Skip ............................... 37
Programmable Band-Scan Limits .................... 38
Smart Search Operation .................................. 39
Priority Channel Monitoring ........................... 40
Priority Revert Mode ...................................... 41
ARTS
TM
: Auto Range Transpond System ......
42
ARTS Basic Operation ................................... 42
ARTS Modes ................................................. 43
CW ID (Morse Identifier) Set up ..................... 43
Packet Operation .............................. 44
Miscellaneous Settings ......................45
Time-Out Timer ............................................. 45
Automatic Power-Off ..................................... 45
FM Bandwidth & Mic Gain Control ................ 46
Programmable Microphone Keys (ACC/P1/P2) 47
Resetting the CPU ............................. 48
Reset all M
ENU
settings: .................................. 48
CPU master reset for all memories
and M
ENU
settings: ..... 48
Transceiver Cloning .......................... 49
Menu System ..................................... 50
Menu Selection Summary ............................... 50
Menu Selection Details ................................... 51
FT-2600M OPERATING MANUAL 1
General Description
The FT-2600M is a deluxe, compact FM mobile transceiver providing high power output
and outstanding receiver performance for the 144 MHz band. Included in the FT-2600M’s
feature complement are:
m 60 Watts of power output, with selection of four power levels for every operating
situation.
m Expanded receiver coverage: 134-174 MHz.
m Keyboard entry of operating frequencies from the microphone.
m Excellent protection from receiver intermodulation distortion, thanks to Yaesu’s re-
nowned Advanced Track Tuning front end.
m Outstanding packet radio capability at 1200 or 9600 bps with easy interface via a
dedicated rear-panel jack.
m 175 memories which can store repeater shifts, odd repeater shifts, CTCSS/DCS tones,
and 8-character Alpha-Numeric labels for easy channel recognition.
m Built-in CTCSS and DCS Encoder/Decoder circuits.
m The Smart Search
™
feature, which automatically sweeps a band and loads active fre-
quencies into dedicated memory banks, is ideal for identifying active repeaters when
visiting a city for the first time.
m Yaesu’s exclusive ARTS
™
(Auto-Range Transponder System), which alerts the opera-
tor when an “out-of-range” condition exists with another ARTS
™
- equipped station.
This feature is especially valuable during search-and-rescue operations with hand-
held units.
m Extensive MENU system, which allows customization of a number of transceiver per-
formance characteristics.
m The Yaesu-exclusive multi-function LCD display.
Additional features include a transmit Time-Out-Timer (TOT), Automatic Power-Off (APO),
Automatic Repeater Shift (ARS), plus provision for reduction of the TX deviation in areas
of high channel congestion. And an all-new S-Meter Squelch circuit allows the owner to
set the squelch to open at a programmable setting of the S-Meter, thus reducing guesswork
in setting the squelch threshold.
Congratulations on your purchase of the FT-2600M! Whether this is your first rig, or if
Yaesu equipment is already the backbone of your station, the Yaesu organization is com-
mitted to ensuring your enjoyment of this high-performance transceiver, which should pro-
vide you with many years of satisfying operation. Yaesu’s dealer network and technical
support personnel stand behind every product we sell, and we invite you to contact us
should you require technical advice or assistance.
We recommend that you read this manual in its entirety prior to installing the FT-2600M,
so that you fully understand the capabilities of your new transceiver.
