Page 1/27
144/430 MHz
DUAL BAND TRANSCEIVER
FT-65R
FT-65E
Operating Manual
Contents
General Description ............................................ 1
Features of the FT-65R/E ................................ 1
About this manual ............................................ 2
Downloading the “Advance Manual” ............... 3
Accessories & Options ....................................... 4
Supplied Accessories ...................................... 4
Available Options............................................. 4
Safety Precautions (Be Sure to Read) ............... 5
Control & Connections (Top & Front Panel) ... 11
Controls & Connections (Side Panel) .............. 12
Controls & Connections (LCD) ......................... 13
Normal operation display ............................... 13
The Set Mode and Preference Mode display 13
Display of features and settings .................... 14
Controls & Connections (Keypad) ................... 15
Installation of Accessories ............................... 16
Antenna Installation ....................................... 16
Preparation of SBR-25LI Battery Pack .......... 16
Installing the Battery Pack ....................... 16
Removing the Battery Pack ..................... 17
Attaching the Belt Clip ................................... 17
Charging the Battery Pack................................ 18
About Desktop charger lamp ........................ 18
Low Battery Indication ................................... 19
About Battery Indicator Icons .................. 19
Approximate Operating Time and Remaining
Charge Level Indication........................... 19
Basic Operation ................................................. 20
Turn the Power ON and OFF ........................ 20
Adjust the Audio Volume Level and Squelch
Setting ........................................................... 20
Changing between VFO mode and Memory
mode ............................................................. 20
Selecting the Operating Band ....................... 20
Frequency Navigation ................................... 21
(1) Tuning Frequency .............................. 21
(2) Direct Keypad Frequency Entry ......... 21
(3) Scanning ............................................ 21
Transmission ................................................. 22
Changing the Transmit Power Level ....... 22
Activating the Set Mode ................................ 23
How to use the
[
P1
]
-
[
P4
]
keys ....................... 23
(1) One touch recall of the preferred status
................................................................ 23
(2) Set Mode Recall feature .................... 23
Preset Functions assigned to the [P1] to [P4]
keys ......................................................... 24
Setting the Preferred Operating Mode .......... 24
Advanced Operation ......................................... 25
Turning the Keylock Feature ON and OFF .... 25
Change the key locking scheme ............. 25
Change the LCD and keypad back light setting ..
...................................................................... 25
Disabling the Keypad and Scan Stop Beeper 26
Repeater Operation ........................................... 27
Repeater Shifts .............................................. 27
Automatic Repeater Shift (ARS) .................... 27
Manual Repeater Shift Setting ...................... 28
Tone Calling (1750 Hz) .................................. 29
Memory Mode .................................................... 30
Memory Storage ............................................ 31
Memory Recall .............................................. 32
Changing the memory label (tag) name ........ 32
HOME Channel Memory Recall .................... 33
Changing the Home Channel Frequency 33
Memory Offset Tuning ................................... 33
Deleting Memories ........................................ 34
Weather Broadcast Channels ....................... 35
Severe Weather Alert .............................. 35
Scanning ............................................................ 36
Setting the Scan-Resume Technique ...... 36
VFO Scanning ............................................... 37
Manual VFO Scan ................................... 37
Programmed Mode (VFO) Scan.............. 37
Input Character/Symbol List ............................. 39
Set (Menu) Mode ................................................ 40
Troubleshooting ................................................ 44
The transceiver does not turn on............. 44
There is no sound.................................... 44
There is no transmission of radio waves. 44
The keys or PTT do not respond. ............ 44
The battery pack cannot be charged or
battery power depletes immediately after
charging................................................... 45
Specifications .................................................... 46
General.................................................... 46
Transmitter .............................................. 46
Receiver .................................................. 47
“AUTO” Mode Preset Operating Parameter .... 47
USA Version ............................................ 47
Asian/European Version .......................... 47
General Description
Features of the FT-65R/E
Congratulations on your purchase of the FT-65R/FT-65E Yaesu amateur
transceiver!
FT-65R/E is a dual band FM transceiver, ruggedly constructed to meet com
-
mercial specications. It is packed with the following popular and valuable
features demanded by Amateur Radio operators around the world.
Long-Life Battery
Supplied 7.4 V 1,950 mAh lithium ion battery.
Optional 7.4 V 2,500 mAh lithium ion battery.
5 Watts of Reliable RF Power
RF Power Output 5.0 W (High) / 2.5 W (Middle) / 0.5 W (Low) (@7.4 V)
Four Quick Recall Keys (User Programmable) for Individual Preferences
Set Mode Recall feature and Quick Memory Feature.
Powerful Audio
Bridged Transless (BTL) amplier provides One Full Watt of Audio for
operation in noisy environments.
Rugged Body Construction
IP54 Rating and MIL-STD-810-C, D, E certied.
Lockout Capabilities
Keypad/PTT Lockout.
Emergency Features
Emergency Operation (Alarm, SOS Flash and HOME channel display),
LED Flash light equipped.
FM Radio Broadcast Receiver Feature
1FT-65R/FT-65E Operating Manual
