Page 1/8
Gigabit Ethernet
PoE Switch 24-port PoE +
2-port SFP, 370W PoE
budget
Quick Installation Guide
DN-95348-1
2
Table of Contents
1. Introduction ............................................................................. 2
2. Features ................................................................................... 3
3. Package Contents ..................................................................... 3
4. Specifications ........................................................................... 3
5. External Component Description ............................................. 5
5.1 Front Panel ......................................................................... 5
5.2 Real Panel ........................................................................... 7
6. Installing and Connecting the Switch ....................................... 8
6.1 Installation ......................................................................... 8
6.2 Rack-mountable Installation in 19-inch Cabinet ................ 8
6.3 Connect Computer (NIC) to the Switch ........................... 10
6.4 Switch connection to the PD ............................................ 10
1. Introduction
The DIGITUS 24-Port Gigabit Rack mount Switch with 24 Power over
Ethernet ports and two additional SFP Fiber Port, offers your network
significant improvement in terms of performance and efficiency. Thanks
to PoE support, you only need a single (network) cable for power and
data transfer. This switch makes it much easier to connect devices such
as access points, network cameras, and IP telephones, and requires far
less cabling than alternatives. It also allows you to extend your network
in places where there are no power supply cables or sockets available.
The switch does not require any configuration and therefore guarantees
quick and seamless integration into the network.
Moreover, can be manually switched to a Normal mode, or Flow Control
mode, or VLAN mode to suitable for various occasions flexibly. Based on
Gigabit Ethernet Technology, it is essential to helping solve network
bottlenecks that frequently develop as more advanced computer users
and newer applications continue to demand greater network resources.
3
2. Features
1. Supporting Normal mode, VLAN mode and Flow control mode,
flexible to switch
2. Gigabit Ethernet Speed
3. Additional 2 port SFP-Uplink for Fiber Technology
4. Rack mountable in system rack (1U)
5. 24 x 10/100 / 1000 Mbps self-adapting RJ45 ports,
support port auto-flip (Auto MDI/MDIX);
6. 2 x 1000 Mbps SFP ports;
7. The UTP port supports the auto-negotiation function and
automatically configures the transmission mode and the
transmission rate
8. Use of Store-and-Forward architecture
3. Package Contents
ï‚Ÿ Gigabit Ethernet PoE Switch 24-port PoE + 2-port SFP,
370W PoE budget
ï‚Ÿ Power cord
ï‚Ÿ QIG
4. Specifications
Hardware Specifications
Standards and Protocols
IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab,
IEEE 802.3x, IEEE 802.3az, IEEE 802.3at,
IEEE 802.3af
Interface
24 x 10/100 / 1000Mbps self-adaptive
RJ45 ports, support port auto flip (Auto
MDI / MDIX)
2 x 1000Mbps optical fiber adaptive ports
Network Media
ï‚Ÿ 10Base-T: UTP category 3, 4, 5 cable
(maximum 100m)
ï‚Ÿ 100Base-Tx: UTP category 5, 5e cable
(maximum 100m)
Product Specifications
| Brand: | Digitus |
| Category: | Switch |
| Model: | DN-95348-2 |
