Page 1/4
Model:
Host Interface:
I/O Port:
DSH-300U3
USB 3.0
One Upstream USB 3.0 Port Type B Port ( )
Five Downstream USB 3.0 Type A Ports ( )
One SD and one MicroSD slot 2TB max( )
One Gigabit Ethernet Port 10/100/1000Base-T Ethernet RJ-45 Connector( )
One HDMI 1.3 Port with Audio( )
One DVI-I Port 24pin + 5pin Female connector( )
One Microphone 3.5mm Mono Audio In( )
One Headphones 3.5mm Stereo Audio Out( )
Audio Component:
Power:
Resolutions:
Output: 2 CH Analog Output via Audio out , 6 CH Digital via HDMI( ) ( )
Input: Mic Mono( )
Input: AC 100-240V, 50~60Hz
Input: DC 5V / 4A
HDMI 2048x1152 Max, DVI 1920x1200 Max
Designed to works with the latest Windows
OS and OS X using Standard USB 3.0
SuperSpeed Technology for the fastest
connectivity and Compatibility.
Dual Display using HDMI and DVI to provide
two monitors for Extended/Mirror or
Primary Display mode using the latest
DisplayLink Technology.
Dual support for Full HD 1080p using two
external monitor for workstation capability
with varies display mode.
One USB 3.0 connection to the system
provide full functionality to all Display, Network,
Audio, Card Reader and USB 3.0 ports.
Dock Designed for Audio Output with 2.1CH
Headphone or Speakers and Audio Input for
Microphone to simplify connectivity.
Support Gigabit Ethernet Wired connectivity
for the fastest network speed and yet it is
also compatible with 10/100 speed.
With Five USB 3.0 port, you can connect many
peripherals like Keyboard, Mouse, External
Storages, smartphone charging and more.
Dedicated slot for SD and MicroSD card
reader with concurrent usage and support
the latest SD Memory Card Technology.
Power
port
Upstream
port
5 USB 3.0 port
DVI-I HDMI
port
Gigabit
Network port
MicrophoneHeadphoneMicro SD
card slot
SD
card slot
SD activity
LED
Power
LED
Copyright © 2014 Vantec Thermal Technologies. All Right Reserved. | All Registered Trademarks Belong To Their Respective Companies.
Model: DSH-300U3
Information in this document is subject to change without notice.
Reproduction of these materials in any manner whatsoever without written permission is strictly forbidden.
Printed in China
Printed on Recycled Paper.
Comprobar el contenido del producto.
Lieferumfang prüfen.
Vérifier le contenu de l'emballage.
Controllare il contenuto del prodotto.
Verify the package contents.
1.
ﺞﺘﻨﻤﻟﺍ ﺕﺎﻳﻮﺘﺤﻣ ﻦﻣ ﻖﻘﺤﺗ
Instalar el CD con los controladores incluidos.
Mitgelieferte Treiber-CD einlegen.
Installer le CD de pilotes inclus.
Installare il CD con i driver in dotazione.
Insert the provided Drivers CD into your CD Drive to
start the installation.
2.
ﺞﻣﺍﺮﺑ ﻰﻠﻋ ﻞﻤﺘﺸﻳ ﻱﺬﻟﺍ ﻖﻓﺮﻤﻟﺍ ﻁﻮﻐﻀ ﺍﻤﻟ ﺹﺮﻘﻟﺍ ﺐﺁﺭﻞﻴﻐ ﻟﺍﺸﺘ
Buscar la carpeta DSH-300U3 y ejecutar el archivo setup.exe.
DSH-300U3-Ordner suchen und setup.exe ausführen.
Naviguer vers le dossier DSH-300U3 et exécuter setup.exe.
Selezionare la cartella DSH-300U3 e avviare setup.exe.
Browse to DSH-300U3 folder and run the setup.exe.
3.
ﺪﻠﺠﻤﻟﺍ ﺽﺮﻌﺘﺳﺍ200U3DSH- ﺩﺍﺪ ﺍﻋﻹ ﻒﻠﻣ ﻭﺷﻐﱢﻞ.exesetup
Seguir las instrucciones que aparezcan en la pantalla hasta completar la instalación.
Bildschirmanweisungen zum Abschließen der Installation befolgen.
Suivez les instructions à l'écran jusqu’à ce que l'installation soit terminée.
Seguire le istruzioni a video fino al completamento dell'installazione.
Follow the instruction on the screen until the
installation is completed.
4.
ﺖﻴﺒﺜ ﺍ ءﺎﻬ ﺍ ﻰﺘﺣ ﺔﺷﺎﺸﻟﺍ ﻰﻠﻋ ﻭﺮﻌﻤﻟﺍ ﺕﺎﻤﻴﻠﻌﺘﻟﺍ ﻊﺒﺗﺍﺘﻟ ﺘﻧ ﺔﺿ
Conectar la estación de acoplamiento de vídeo y los periféricos.
Video-Dockingstation und Peripheriegeräte anschließen.
Connecter la station d'accueil et les périphériques vidéo.
Collegare la stazione docking video e le periferiche.
Connect the Video Docking station and peripherals.
5.
HDMI DVI
ﺔﻴﻓﺮﻄﻟﺍ ﺓﺰﻬﺟﻷﺍﻭ ﻮﻳﺪﻴﻔﻟﺍ ﺜﺗ ﺓﺪﻋﺎﻗ ﻭﺻﱢﻞ ﺖﻴﺒ
