Page 1/8
Installation Instructions
Havis Weatherproof Docking Station
For Panasonic CF-19 Toughbook
DS-PAN-214_OMN_10-11
www.havis.com
1-800-524-9900
Supplement to Ownerâs Manual
DS-PAN-214 & DS-PAN-214-2
Havis, Inc.
75 Jacksonville Road, PO Box 2099
Warminster, PA 18974
47801 Anchor Court
Plymouth, MI 48170
www.havis.com 1-800-524-9900
www.havis.com ⢠1-800-524-9900
1 6
1). Taking care to remove any excess moisture which may be present, remove
Docking Connector Cover by unscrewing the two thumb screws. Use the
Tether Loop if desired to attach Docking Connector Cover to a îxed object.
(Tether not included) If Tether option is not used, store Docking Connector
Cover in a safe, dry location.
2). Follow Docking and Undocking instructions in the Ownerâs Manual (Pages 7-8),
making sure to apply downward pressure to the computer while latching in
order to suďŹciently compress the Gasket surrounding the Docking Connector.
3). Taking care once again to remove any excess moisture from the computer
and Docking Station, Undock the computer according to the Ownerâs Manual
(Page 8) and lower the Docking Connector Cover on the Docking Station.
Hand tighten the two thumb screws.
DS-PAN-214 DS-PAN-214-2
Before Beginning Docking & Undocking
(Original Instructions)
⢠READ ALL INSTRUCTIONS THOROUGHLY BEFORE BEGINNING INSTALLATION.
⢠DO NOT MATE COMPUTER TO DOCKING STATION UNLESS COMPUTERâS DOCKING
CONNECTOR ACCESS DOOR IS FULLY OPEN OR DAMAGE MAY RESULT.
⢠ALWAYS USE DOCKING CONNECTOR COVER WHEN DOCKING STATION IS NOT IN USE.
⢠TO MAXIMIZE THE LIFE OF YOUR PRODUCT, IT MAY BE NECESSARY TO ROUTINELY
REMOVE EXCESS MOISTURE OR CONTAMINANTS FROM THE DOCKING STATION
EXTERNAL SURFACES, ESPECIALLY THE LOCK AND REGIONS SURROUNDING THE
DOCKING CONNECTOR AND CABLE CONNECTORS.
This document is a supplement to the supplied Ownerâs Manual,
and applies only to installation and use of the IP65 compliant
DS-PAN-214 & DS-PAN-214-2 Docking Stations for the Panasonic
CF-19 laptop computer.
For questions regarding the set-up of your DS-PAN-214 or
DS-PAN-214-2 Docking Station, please contact Havis at
1-800-524-9900 or visit www.havis.com for additional
product support and information.
This Supplement applies to the following Part Numbers:
Tether Loop
Thumb Screws
www.havis.com ⢠1-800-524-9900
5 2
5). Lower Cable Cover into place on Docking Station, making sure all six cable
exits have a Grommet with cable inserted, or a Grommet with Grommet Plug
inserted. Fasten #8-32 Pan Head Phillips Screws in 6 places as shown.
Torque all six #8-32 Pan Head Phillips Screws to 20 Âą 10% in-lbs.
6). Insert Zip Ties into strain relief holes on the Cable Cover in order to secure
exiting cables. Cut oďŹ excess from connected Zip Ties. Ensure that Zip Tie
is routed beneath cable for adequate strain relief.
If you are routing Antenna cable(s) (Part # DS-PAN-214-2), use Push Pin Zip Ties
supplied with the Docking Station Hardware Kit to secure the cable(s) to the Strain
Relief Holes at the back of the Docking Station. Then route the cables to the cable
bundle and secure as speciîed in the Ownerâs Manual (Page 6, Step 5).
Parts Included
Installation & Cable Management (continued)
Port Replication
Lock
Latch Handle
Docking Connector
Gasket
Front Hooks
Docking Station
Additional Parts
1. Mounting Bracket (1)
2. Cable Cover (1)
3. Docking Connector Cover (1)
with Thumb Screws
4. #8-32 Pan Head Phillips Screws (7)
5. Grommets (7)
6. Grommet Plugs (7)
7. Zip Ties (7)
8. Foam Tape
9. DS-PAN-210 Series Ownerâs
Manual & Hardware Kit
(not shown)
Includes: Zip Ties (4), Keys (2),
1/4â-20 Screws (3), M5 Screws (4)
Antenna Strain
Relief Holes (4)
Strain Relief Hole
Forward Facing Connectivity
Rearward Facing Connectivity
(Part # DS-PAN-214-2 only)
NOTE: A maximum of six (6)
connections can be made on
DS-PAN-214 & DS-PAN-214-2
Docking Stations
Ethernet
(RJ45)
Serial
(x2)
VGA
Power
Input
USB 2.0
(x3)
Antenna B Antenna A
Speaker / Headphone
Microphone
Product Specifications
| Brand: | Havis |
| Category: | Other computer accessories |
| Model: | DS-PAN-214-2 |
