Read below π the manual in Italian for Intellinet 561686 (12 pages) in the Switch category. This guide has been helpful for 30 people and has been rated 4.5 stars on average by 2 users
Page 1/12
2
The Intellinet 6-Port Fast Ethernet Switch with 4 PoE Ports (1 x
High-Power PoE) offers an array of time-saving, cost-effective
features while providing superior network throughput. No
configuration is required and installation is plug and play.
For specifications, visit intellinetnetwork.com. Register your product at
register.intellinet-network.com/r/561686 or scan the QR code on the cover.
Features
β’ Provides up to four PoE network devices with power and data
β’ Manual PoE extend mode (reduces network speed
and extends PoE support to 250 m)
β’ One high-power PSE PoE Port with power up to 60 W (port 1),
three IEEE 802.3at/af PSE PoE Ports with up to 30 W each
β’ PoE power budget of 65 watts
β’ Two RJ45 Fast Ethernet uplink ports
β’ Backplane speed of 1.2 Gbps
Front Panel
LED Color Status Operation
Link Yellow
On Valid port connection
Blinking Sending or receiving data
Off No link established.
PoE Green
On The connected device is receiving power.
Off No PSE/PoE device is linked.
SPD Green
On 100 Mbps speed
Blinking 10 Mbps speed
PWR Green
On Power on
Off Power off
English
Instructions 6-Port Fast Ethernet Switch with 4 PoE Ports (1 x High-Power PoE)
3
Slide Switch
STANDARD: default mode; allows normal
communication between ports.
EXTEND: open MTU VLAN, set PoE ports to full 10 Mbps
and extend Ethernet up to 250 meters (820 ft.)
Connections
Connections
1 Use Ethernet cable (Cat5e min.) to connect powered device(s) to PoE port(s).
2 Use Ethernet cable (Cat5e min.) to connect switch to uplink port(s).
3 Wire the grounding terminal to an earth-grounding
object to prevent power spikes.
4 Use the included power cord to connect the device (on the rear panel) to an
AC outlet. The device supports AC 100 β 240 V, 50/60 Hz.
Placement
Desktop Installation
Prior to use, place/position the switch:
β’ on a level surface with at least 25 mm (approx. 1β) of clearance for ventilation
β’ away from sources of electrical noise: radios, transmitters,
broadband amplifiers within 100 m (approx. 328β) of
network devices itβs to be connected to.
1
2
3
4
5
1 2 3 4
Instructions
English
6-Port Fast Ethernet Switch with 4 PoE Ports (1 x High-Power PoE)
Data
Power & Data
Product Specifications
| Brand: | Intellinet |
| Category: | Switch |
| Model: | 561686 |
